| Antwerpen 25 June 2009 |
 |
| Ant 25/06/09 |
|
Name |
K-STORM |
|
Type |
Containership |
|
IMO-number |
9389435 |
|
Call sign |
V2DV8 |
|
Flag |
Antigua & Barbuda |
|
Port of registry |
St. John's |
|
GT |
8.246 t |
|
DWT |
11.190 t |
|
NT |
4.002 t |
|
Number of 20ft containers |
974 |
|
Container capacity at 14t |
584 |
|
Reefer capacity |
150 |
|
Length |
139,60 m overall 133,25 m between perpendiculars 133,65 m registered |
|
Breadth |
22,20 m moulded |
|
Draught |
7,364 m |
|
Forecastle |
38,50 m |
|
Poop |
10,64 m |
|
Freeboard |
2.200 mm |
|
Depth |
9,50 m moulded |
|
Speed |
Service: 17,9 knots Max.: 18,4 knots |
|
Built |
2008 |
|
Keel laid |
27.03.2008 |
|
Launch date |
03.07.2008 |
|
Date of completion |
14.11.2008 |
|
Builder |
Detlef Hegemann Rolandwerft GmbH & Co. KG |
|
Yard number |
244 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Single hull Double bottom |
|
Watertight bulkheads |
7 |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 9M43C - 4 stroke single acting 9 cylinder 430 x 610 mm diesel engine - 8.400 kW at 500 rpm Year of manufacture: 2008 Manufacturer: Caterpillar Motoren Rostock GmbH |
|
Propeller |
1x Controllable pitch propeller - aft at 171 rpm |
|
Boilers |
1x Steam boiler, oil fired - 9,0 bar Heating surface: 15,0 m² 1x Steam boiler exhaust gas heated - 9,0 bar Heating surface: 172,0 m² Year of manufacture: 2008 Manufacturer: Aalborg Industries A/S |
|
Electric installations |
1x Plant 450 V - 1.092 kVA 1x Plant 450 V - 1.495 kVA 1x Plant 450 V - 546 kVA 1x Plant 24 V - 105 Ah 1x Plant 24 V - 105 Ah 1x Plant 24 V - 135 Ah 1x Plant 24 V - 225 Ah |
|
Shaft generator |
1.196 kW / 1.495 kVA |
|
Generators |
2x Main diesel generatorset each 436,8 kW / 546 kVA |
|
Emergency generator |
1x Diesel generatorset 546 kVA |
|
Batteries |
2x Batteries for start emergency engine each 225 Ah 1x Battery for UPS radio - 135 Ah 1x Battery for automation - 105 Ah 1x Battery for UPS navigation - 105 Ah |
|
Compressed Air Receiver(s) |
2x Receivers each 750 litres - 30,0 bar |
|
Bow thruster |
1x Transverse thruster - 1.000 kW, forward |
|
Anchor equipment |
3x Anchors weight each 5.610 kg Chain length: 577,50 m |
|
Crew size |
19 |
|
Manager |
K&K Schiffahrts GmbH & Co. KG |
|
Owner |
MS "K-STORM" Schiffahrts GmbH & Co. KG |
|
Renamed |
Seaboard Caribe |
