Name |
MSC MAYA |
|
Type |
Cellular containership |
|
IMO-number |
9708679 |
|
Call sign |
3EZI |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
192.237 t |
|
DWT |
221.517 |
|
NT |
111.423 t |
|
Number of 20ft containers |
In hold: 7.966 On deck: 11.258 Total: 19.224 |
|
Container capacity 14t |
13.500 |
|
Reefer capacity |
1.800 |
|
Length |
395,49 m overall 379,40 m between perpendiculars |
|
Breadth |
59,08 m extreme |
|
Draught |
Summer: 17,10 m |
|
Depth |
30,30 m |
|
Speed |
22,8 knots |
|
Built |
2015 |
|
Keel laid |
26/12/2014 |
|
Launch date |
30/05/2015 |
|
Date of completion |
19/08/2015 |
|
Builder |
DSME - Daewoo Shipbuilding & Marine Engineering Okpo Shipyard South Korea |
|
Yard number |
4280 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x Hyundai/MAN-B&W 11S90ME-C10 - 2 stroke single acting 11 cylinder 900 x 3.260 mm combustion engine Mcr 65,500 kW / 84.975 hp at 82,0 rpm Builder: Hyundai Heavy Industries Co Ltd - South Korea |
|
Propellers |
1x Fixed pitch propeller - aft at 82,0 rpm 5 blades - Diameter: 10,50 m |
|
Boilers |
1x Auxiliary boiler, oil/gas fired 3x Auxiliary boiler, exhaust gas heated |
|
Generators |
2x MAN-B&W 8L32/40 main diesel generatorsets each Mcr 5.500 kW connected with generators each 4.400 kW 2x MAN-B&W L32/40 main diesel generatorsets each Mcr 4.500 kW connected with generators each 3.900 kW |
|
Emergency generator |
1x MAN D2842LE201 diesel generatortset |
|
Bow thruster |
2x Tunnel thruster 2.500 kW / 3.399 bhp, forward |
|
Tank capacities |
Ballast: 60.566,5 m³ |
|
Anchor capacity |
Length: 770,00 m Diameter: 132 mm |
|
Cargo gear |
Gearless |
|
Crew size |
23 |
|
Commercial manager |
MSC - Mediterranean Shipping Company S.A chemin Rieu, 12-14 1208 Geneva Switzerland |
|
ISM manager |
Mediterranean Shipping Co Srl Via Francesco Ciampa 29 80063 Piano di Sorrento NA Italy |
|
Registered owner |
Ocean Genius Shipping Limited Care of MSC Mediterranean Shipping Co SA chemin Rieu, 12-14 1208 Geneva Switzerland |
|
Latest data adjustment |
08 November 2023 |
