Westerschelde 28 February 2017 |
 |
 |
 |
 |
 |
||||
| Westerschelde 28/02/17 | Westerschelde 14/03/19 | Westerschelde 14/08/18 | Zeebrugge 16/08/16 | Westerschelde 24/05/17 | ||||
|
Name |
CMA CGM POINTE DES COLIBRIS |
|
Previous names |
04/2006 - 11/2008 CMA CGM Camelia 11/2008 - 01/2016 Camelia |
|
Type |
Cellular containership |
|
IMO-number |
9314947 |
|
Call sign |
CQAA7 |
|
Flag |
Portugal |
|
Port of registry |
Madeira |
|
Previous flag |
2006 - 2007 Bahamas, Nassau 2007 - 2017 Hong Kong - China, Hong Kong - Call sign: VRCP9 |
|
GT |
28.927 |
|
DWT |
Summer: 39.200 t |
|
NT |
15.033 |
|
Number of 20ft containers |
On deck: 1.798 In hold: 1.026 Total: 2.824 |
|
Container capacity 14t |
2.030 |
|
Reefer points |
On deck: 332 In hold: 254 Total: 586 |
|
Length |
222,17 m overall 210,00 m between perpendiculars |
|
Breadth |
30,07 m extreme |
|
Draught |
12,02 m |
|
Keel to mast end |
53,00 m |
|
Depth |
16,80 m |
|
Forecastle |
27,33 m |
|
Freeboard |
4.837 mm |
|
Speed |
Max.: 23,0 knots |
|
Built |
2006 |
|
Keel laid |
09/02/2005 |
|
Launch date |
23/02/2006 |
|
Date of completion |
07/04/2006 |
|
Builder |
Hyundai Mipo Dockyard Co., Ltd. Ulsan South Korea |
|
Yard number |
0422 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Single hull double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
6 |
|
Continuous decks |
1 |
|
Main engine |
1x HHI/MAN-B&W 7K80MC-C Mk 6 - 2 stroke 7 cylinder 800 x 2.300 mm combustion engine 25.270 kW / 30.870 hp at 104,0 rpm Builder: Hyundai Heavy Industries Co., Ltd. |
|
Propellers |
1x Fixed pitch propeller Builder: Hyundai Heavy Industries Co., Ltd. |
|
Boilers |
1x Auxiliary boiler, composite (steam boiler, oil fired / exhaust gas heated) - 10,0 bar Heating surface: 28,0 m² Heating surface: 695,0 m² Builder: Alfa Laval Aalborg A/S |
|
Generators |
4x MAN-B&W type 8L28/32H main diesel generatorsets each 1.600 kW / 2.000 kVA Builder: Hyundai Engine & Machinery Co., Ltd.(B&W), Ulsan - South Korea |
|
Emergency generator |
1x Sisu diesel 634 DSBIG diesel generatorset 187,5 kVA |
|
Compressed air receivers |
2x Receivers each 8.500 litres - 30,0 bar 1x Receiver 300 litres - 30,0 bar |
|
Bow thruster |
1x Brunvoll AS FU80LTC2000 transverse thruster 1.100 kW |
|
Number of holds |
6 |
|
Number of hatches |
11 |
|
Tank capacities |
Ballast: 11.340,4 m³ |
|
Anchor equipment |
3x Anchors weight each 9.900 kg Length: 660,00 m Diameter: 78 mm |
|
Lifting equipment |
2x Cranes - SWL 0,8 t 1x Crane - SWL 6,3 t 1x Crane - SWL 6,5 t |
|
Cargo gear |
Gearless |
|
Crew size |
25 |
|
Manager |
Marlow Ship Management Deutschland GmbH & Co. KG Breite Str. 61 22767 Hamburg Germany |
|
Operator |
CMA CGM SA The French Line Marseille France |
|
Registered owner |
"AS CAMELLIA" Schifffahrtsgesellschaft mbH & Co. KG |
|
Previous owner |
Two Armania Shipping Ltd. |
|
Renamed |
2019 AS Camellia Portugal, Madeira - Call sign: CQAA7 Owner: "AS CAMELLIA" Schifffahrtsgesellschaft mbH & Co. KG Manager: Marlow Ship Management Deutschland GmbH & Co. KG |
|
Latest data adjustment |
19 November 2024 |
