Name |
CMA CGM CHRISTOPHE COLOMB |
|
Type |
Cellular containership |
|
IMO-number |
9453559 |
|
Call sign |
9HA5397 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
Previous flag |
11/2009 - 03/2021 France, Marseille - Call sign: FNUY |
|
GT |
151.446 |
|
DWT |
164.473 t |
|
NT |
86.099 |
|
Number of 20ft containers |
13.880 |
|
Container capacity 14t |
10.000 |
|
Reefer point |
800 |
|
Length |
365,50 m overall 349,50 m between perpendiculars |
|
Breadth |
51,20 m |
|
Draught |
15,50 m |
|
Freeboard |
12.500 mm |
|
Depth |
29,90 m |
|
Speed |
Max.: 24,1 knots |
|
Built |
2009 |
|
Date of completion |
10/11/2009 |
|
Builder |
Daewoo Shipbuilding & Marine Engineering Co. Ltd. Geoje South Korea |
|
Yard number |
4156 |
|
Hull material |
Steel |
|
Continuous decks |
1 |
|
Main engine |
1x Wärtsilä 14RT-Flex96C - 14 cylinder combustion engine 75.275 kW / 102.276 hp at 100,0 rpm Licence: Wärtsilä Builder: Hyundai Heavy Ind. Co., Ltd. - Engine & Mach. Div. |
|
Propellers |
1x Screw propeller solid |
|
Boilers |
1x CHO 40,14 m² / 10,0 bar 1x CHR 326,00 m² / 10,0 bar 2x CHR Alfa Laval Aalborg 119,00 m² / 12,0 bar |
|
Generators |
2x Hyundai/HimSen 8H32/40 each diesel generatorsets 4.800 kVA - 3.840 kW - 5435 hp 2x Hyundai/HimSen 7H32/40 each 3.360 kW / 4.755 hp diesel generatorsets 4.125 kVA - 3.300 kW - 4.755 hp |
|
Bow thruster |
3.600 kW |
|
Number of holds |
9 |
|
Total capacity of holds |
316.188,50 m³ |
|
Tank capacities |
Fuel: 15.630,3 m³ |
|
Cargo gear |
Gearless |
|
Crew |
31 |
|
Manager |
CMA CGM - Compagnie Maritime D'Affrètement - Compagnie Générale Maritime Marseille France |
|
Operator |
CMA CGM - Compagnie Maritime D'Affrètement - Compagnie Générale Maritime |
|
Owner |
SNC Nieuhof 30 Avenue Pierre Mendes Paris, 75013 France |
|
Previous owner |
CMA CGM SA The French Line |
|
Latest data adjustment |
30 November 2024 |
