| Zeebrugge 21 November 2010 |
 |
 |
 |
 |
||||||
| Zeebrugge 21/11/10 | Zeebrugge 21/11/10 | Zeebrugge 18/04/11 | Zeebrugge 05/0508 |
|
Name |
CMA CGM FIDELIO |
|
Type |
Cellular Containership |
|
IMO-number |
9299642 |
|
Call sign |
FMFS |
|
Flag |
France |
|
Previous flag |
02.06.2006 Bahama |
|
Port of registry |
Marseille |
|
GT |
107.898 t Suez: 111.355,4 t |
|
DWT |
Summer: 113.889 t |
|
NT |
50.109 t Suez: 101.706,75 t |
|
Number of 20ft containers |
9.415 |
|
Container capacity 14TH |
6.919 |
|
Reefer Point |
700 reefer |
|
Length |
349,05 m overall |
|
Breadth |
42,80 m over ll |
|
Draught |
Summer: 15,02 m |
|
Freeboard |
12.800 mm |
|
Depth |
27,30 m |
|
Speed |
25,7 knots |
|
Built |
2006 |
|
Date of completion |
05.2006 |
|
Delivery date |
26.05.2006 |
|
Builder |
Hyundai Heavy Industries Co., Ltd. |
|
Yard number |
1648 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Watertight compartments |
13 |
|
Continuous decks |
2 |
|
Propelling engine |
1x MAN B&W 12K98MC-C - 2 stroke 12 cylinder 980 x 2660 mm diesel engine - 68.640 kW / 93.261 hp at 94,0 rpm Built: 2005 Builder: Hyundai Heavy Industries Engine & Mach. Div. Ulsan - South Korea |
|
Number of screws |
1x Screw propeller solid at 94 rpm |
|
Boilers |
1x CHO Aalborg 40,14 m² - 10,0 bar |
|
Electrical installation |
Power Voltage: 6.600 V |
|
Generators |
3x Main diesel generatorsets each 2.933 kVA - 2.346 kW - 3.136 hp |
|
Emergency generators |
1x Diesel generatorset 625 kVA - 500 kW - 815 hp |
|
Bow thruster |
2.500 kW |
|
Cargo holds |
10 |
|
Cargo hatchways |
20 |
|
Fuel capacity |
14.602,40 m³ |
|
Cargo Gear |
Gearless |
|
Crew |
28 |
|
Manager |
CMA CGM |
|
Operator |
CMA CGM |
|
Owner |
Gie Opera 7 Bail |
|
Owner as completed |
GIE Opera 7 Bail |
|---|
