Westerschelde 18 December 2017 |
Westerschelde 31/03/20 |
Name |
MAERSK GUATEMALA |
Type |
Cellular containership |
IMO-number |
9713375 |
Call sign |
VROS7 |
Flag |
Hong Kong - China |
Port of registry |
Hong Kong |
GT |
113.042 t |
DWT |
119.510 t |
NT |
59.440 t |
Number of 20ft containers |
10.010 |
Length |
337,00 m overall 321,67 m between perpendiculars |
Breadth |
48,31m extreme 48,20 m moulded |
Draught |
15,52 m |
Depth |
27,20 m |
Speed |
Max.: 21,0 knots |
Built |
2015 |
Keel laid |
27/06/2014 |
Launch date |
27/03/2015 |
Date of completion |
02/09/2015 |
Builder |
Jiangsu Yangxi Xinfu Shipbuilding Jingjiang China |
Yard number |
YZJ2013-1104 |
Hull material |
Steel |
Main engine |
1x MAN-B&W 10S90ME-C9.2 - 10 cylinder combustion engine 58.100 kW / 79.016 hp at 84,0 rpm |
Propellers |
1x Nakashima fixed pitch propeller - 6 blades |
Boilers |
1x Auxiliary boiler, oil/gas fired MISSION OS-Tci-5500 1x Auxiliary boiler, exhaust gas heated XS-7V Builder: Alfa Laval Aalborg A/S |
Generators |
2x Daihatsu 8DC-32 main diesel generatorsets each 3.690 kW 2x Daihatsu 6DC-32 main diesel generatorset each 2.648 kW Builder: Daihatsu Diesel Mfg. Co., Ltd. Moriyama Factory |
Emergency generator |
1x Doosan 180 diesel generatorset 500 kW Builder: Doosan Infracore Co., Ltd. |
Tank capacities |
Ballast: 31.530,1 m³ |
Anchor equipment |
Length: 770,00 m Diameter: 114 mm |
Manager |
Seaspan Ship Management Ltd. Granville street Vancouver Canada |
Charterer |
Maersk |
Registered owner |
GC Intermodal XIX, Ltd. |
Latest data adjustment |
13 November 2020 |
