Name |
EVELYN MÆRSK |
|
Type |
Cellular containership |
|
IMO-number |
9321512 |
|
Call sign |
OXHV2 |
|
Flag |
Kingdom of Denmark |
|
Port of registry |
København |
|
GT |
170.794 t registered Suez: 170.916,04 t |
|
DWT |
158.200 t |
|
NT |
55.396 t registered Suez: 151.687,66 t |
|
Number of 20ft containers |
13.460 |
|
Container capacity at 14t |
11.000 |
|
Reefer capacity |
1.000 |
|
Length |
397,71 m overall 376,00 m between perpendiculars |
|
Breadth |
56,40 m moulded |
|
Draught |
Summer: 16,00 m |
|
Keel to mast end |
76,50 m |
|
Freeboard |
8.100 mm |
|
Depth |
30,20 m moulded |
|
Speed |
Service: 24,5 knots Max: 26,0 knots |
|
Built |
2007 |
|
Keel laid |
10/09/2006 |
|
Launch date |
30/01/2007 |
|
Date of completion |
29/03/2007 |
|
Builder |
Odense Steel Shipyard AS (Odense Staalskibsværft A/S) Lindø Denmark |
|
Yard number |
L206 |
|
Hull type |
Single hull |
|
Bulkheads |
Non Tight: 11 Water Tight: 11 Oil Tight: 13 |
|
Main engine |
1x Doosan/Wärtsilä 14RT-FLEX96C - 2 stroke 14 cylinder 960 x 2.500 mm combustion engine 80.080 kW / 108.080 bhp at 102,0 rpm Manufacturer Name: Doosan Engine Co. Ltd. |
|
Propelling system |
1x Six blades solid bronze propeller FP D-9600 PAL 1100 Manufacturer: Mecklenburger Metallguss GMBH |
|
Shaft motor |
2x W/COOLERS 1DM5553-8XS08-Z - 9.000 kW Manufacturer: Siemens AG |
|
Steam piping system |
1x Vertical water tube oil fired auxiliary boiler AQ-10/12W - 14,0 bar Boiler heating surface: 55.000 mm² Manufacturer name: Aalborg Industries Aalborg - Denmark 1x HP exhaust gas boiler AV-6N - 14,0 bar Manufacturer name: Aalborg Industries Aalborg - Denmark 1x LP exhaust gas boiler AV-6N - 12,0 bar Manufacturer name: Aalborg Industries Aalborg - Denmark |
|
Main power distribution system |
1x Combo power / steam turbine generator 1DT3939-8AL02-Z - 10.625 kVA Rated power: 8.500 kW Manufacturer name: SEM DRASOV |
|
Generators |
5x MaK 9M32C main diesel generatorsets each 5.925 kVA / 4.148 kW Manufacturer name: Sem Drasov |
|
Bow thruster |
2x 1.750 each, forward 2x 1.750 each, aft |
|
Number of tanks |
Ballast: 31 Fuel Oil: 22 Lubricating Oil: 8 Sea Water: 7 Fresh Water: 7 Waste Water: 6 Sludge: 6 Diesel Oil: 6 Chain: 2 Hydraulic Oil: 1 |
|
Tank capacities |
Ballast: 61.847 t Diesel oil: 364,50 t Freshwater: 752,60 t Fuel oil: 17.090 t Lube oil: 586,89 t |
|
Hold capacity |
355.164,10 m³ |
|
Grain capacity |
355.190,74 m³ |
|
Lifting equipment |
1x Elevator SSRFC - SWL 0,5 t Manufacture name: Hans Lutz Maschinenfabrik GmbH & Co. 1x Monorail Stores Crane 20T PR - SWL 20,0 t Manufacture name: Dreggen A/S 1x Overhead Engine room Crane aft - SWL 12,5 t Manufacture name:Danish Crane Building A/S 1x Overhead Engine room Crane FWD - SWL 12,5 Manufacture name:Danish Crane Building A/S 1x Stores/Bunker/ Suez Boat Pedestal Crane Port DK40-5T-6.5M/2.5T-8.4M - SWL 5,0 t Manufacture name: Dreggen A/S 1x Stores/Bunker/Suez Boat Pedestal Crane STBD DK40 5T-6.5M/2.5T-8.4M - SWL 5,0 t Manufacture name: Dreggen A/S |
|
Cargo gear |
None |
|
Crew |
28 |
|
ISM & commercial manager |
Maersk Line A/S Esplanaden 50 1263 Copenhagen K Denmark |
|
Registered owner |
A. P. Moller - Maersk A/S Esplanaden 50 1263 Copenhagen K Denmark |
|
Latest data adjustment |
07 June 2022 |
