Ever Champion - IMO 9293765

Name

EVER CHAMPION

Previous name

Conti Champion

Type

Cellular containership

IMO-number

9293765

Call sign

DDZJ2

Flag

Germany

Previous flag

27.04.2007 Marshall Islands

Port of registry

Hamburg

GT

90.449 t

DWT

100.949 t

NT

55.452 t

Number of 20ft containers

8.084

Reefer capacity

700

Length

333,99 m overall

319,00 m between perpendiculars

320,62 m registered

Breadth

43,00 m overall

42,79 m moulded

42,80 m registered

Draught

Summer: 14,50 m

Bridge

149,63 m

Forecastle

160,03 m

Poop

10,40 m

Freeboard

10.100 mm

Depth

20,53 m

Speed

25,2 knots

Line

Evergreen

Built

2005

Keel laid

04.01.2005

Launch date

17.03.2005

Date of completion

30.05.2005

Builder

Samsung Heavy Industries Co., Ltd. Geoje Shipyard
530, Jangpyeong-ri, Sinhyeon-eup
Geoje , Gyeongsangnam-do 656-710
Republic of Korea

Yard number

1513

Hull type

Single hull

Double bottom

Watertight bulkheads

11

Continuous decks

2

Main engine

1x Sulzer 12 RTA96C-B - 2 stroke single acting 12 cylinder 960 x 2.500 mm diesel engine - 68.660 kW

Year of manufacture: 2005

Builder: HSD Engine Co., Ltd.
69 Sinchon-dong
Changwon , Kyungnam 641-370
Republic of Korea

Propeller

1x Solid propeller (keyless) - aft

Boilers

1x Steam boiler, oil fired - 10,0 bar
Heating surface: 40,1 m²

1x Steam boiler, exhaust gas heated - 10,0 bar
Heating surface: 362,0 m²

Year of manufacture: 2004

Manufacturer: Aalborg Industries Ltd.
86 Guangzhou Road North Jiaozhou
266300 Qingdao , Shandong
People's Republic of China

Electric installations

1x 6.600/450 V - 15.282 kVA

1x 440 V - 625 kVA

1x 24 V - 250 Ah

1x 24 V - 920 Ah

Generators

2x MAN-B&W 9L27/36 main diesel generatorsets each 3.525 kVA / 2.820 kW

3x MAN-B&W 7L27/38 main diesel generatorsets each 2.744 kVA / 2.195 kW

Emergency generator

1x Diesel generatorset 625 kVA / 500 kW

Batteries

1x Battery for UPS radio - 200 Ah

2x Batteries for automation each 160 Ah

Compressed air receivers

2x Receivers, each 20.000 litres - 33,0 bar

1x Receiver 500 litres - 33,0 bar

1x Receiver 300 litres - 33,0 bar

1x Receiver150 litres - 8,8 bar

Bow thruster

1x Transverse thruster - 2.500 kW, forward

Anchor equipment

3x Anchors weight each 18.800 kg

Chain length: 742,50 m

Cargo gear

Gearless

Crew

24

Manager

NSB Niederelbe Schiffahrts GmbH & Co. KG
Harburger Str. 47-51
21614 Buxtehude
Federal Republic of Germany

Operator

Evergreen

Owner

Conti 19. Container Schiffahrts GmbH & Co. KG MS "CONTI CHAMPION"
Harburger Str. 4
21614 Buxtehude
Federal Republic of Germany
