Westerschelde 15 May 2017 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 29/06/20 | Westerschelde 29/06/20 | Westerschelde 28/08/18 | Antwerpen 07/05/18 | Westerschelde 03/10/18 | Westerschelde 08/05/17 | |||||
|
Name |
IRENES REMEDY |
|
Previous names |
2004 build as: Irene Relief |
|
Type |
Cellular containership |
|
IMO-number |
9315850 |
|
Call sign |
A8WG3 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
Previous flags |
2005 - 07/2010 Greece - Call sign: SYAQ |
|
GT |
28.592 t |
|
DWT |
Summer: 39.382 t |
|
NT |
14.769 t |
|
Number of 20ft containers |
2.824 |
|
Container capacity 14t |
2.030 |
|
Reefer capacity |
586 |
|
Length |
222,17 m overall 212,18 m between perpendiculars |
|
Breadth |
30,04 m |
|
Draught |
12,01 m |
|
Keel to mast end |
53,00 m |
|
Forecastle |
27,33 m |
|
Freeboard |
4.837 mm |
|
Depth |
16,80 m |
|
Speed |
Max: 24,0 knots |
|
Built |
2005 |
|
Keel laid |
02/09/2004 |
|
Date of completion |
02/02/2005 |
|
Builder |
Hyundai Mipo Dockyard Co., Ltd. Ulsan South Korea |
|
Yard number |
401 |
|
Hull material |
shipbuilding steel (standard) |
|
Hull type |
Single hull Double bottom, continuous from peak to peak bulkhead |
|
Watertight compartments |
10 |
|
Continuous decks |
1 |
|
Main engine |
1x Hyundai/MAN-B&W 7K80MC-C - 2 stroke 7 cylinder 800 x 2.300 combustion engine 25.270 kW / 34.276 hp at 104,0 rpm Built: 2004 Builder: Hyundai Heavy Ind. Co, Ltd. - Engine & Mach. Div., Ulsan - South Korea |
|
Propellers |
1x Fixed pitch propeller - aft at 104,0 rpm |
|
Boilers |
1x Steam boiler, oil fired / exhaust gas heated - 8,83 bar Heating surface 35,0 m² Heating surface 654,0 m² Manufacturer: KangRim Industries Co., Ltd. (1rd Factory) |
|
Electric installations |
Power voltage: 440 V Lighting voltage: 220 V Frequency: 60 Hz |
|
Generators |
4x MAN-B&W 8L28/32H main diesel generatorsets each 2.000 kVA - 1.600 kW - 2.283 hp at 720 rpm |
|
Emergency generator |
1x Diesel generatorset 187 kVA - 150 kW |
|
Batteries |
2x Batteries for UPS radio each 200 Ah |
|
Compressed air receivers |
2x Receivers each 8.500 litres - 30 bar 1x Receiver 300 litres - 30,0 bar 1x Receiver 250 litres - 7,0 bar |
|
Bow thruster |
1x Transverse thruster 1.100 kW |
|
Number of holds |
6 |
|
Total capacity of holds |
52.794 m³ |
|
Number of hatches |
11 |
|
Tank capacities |
Ballast: 11.340 t Fuel: 3.307.9 m³ |
|
Anchor equipment |
3x Anchors weight each 9.900 kg Chain length: 660,00 m |
|
Lifting equipment |
1x Crane - SWL 6,3 t 1x Crane - SWL 6,5 t 2x Cranes - SWL 0,8 t each |
|
Cargo gear |
Gearless |
|
Crew size |
25 |
|
ISM & commercial manager |
Tsakos Conbulk Services TCB Megaron 'Macedonia' 367, Andrea Syngrou Avenue, Palaio Faliro 175 64 Athens Greece |
|
Registered owner |
Harrigan Shipping Corporation 367, Syngrou Avenue Palaio Faliro 175 64 Greece |
|
Previous owners |
Sea Glory Navigation S.A. - Greece |
|
Latest data adjustment |
30 October 2022 |
