Westerschelde 15 April 2018 |
 |
 |
 |
||
| Westerschelde 15/04/18 | Westerschelde 26/10/20 | Westerschelde 02/04/18 | ||
|
Name |
CAPE MANILA |
|
Type |
Cellular containership - Panamax |
|
IMO-number |
9571313 |
|
Call sign |
V7WW8 |
|
Flag |
Marshall Islands |
|
Port of registry |
Majuro |
|
Previous flag |
Cyprus, Limassol - Call sign: 5BPJ4 |
|
GT |
35.708 t |
|
DWT |
Summer: 41.534,6 t |
|
NT |
19.672 t |
|
Number of 20ft containers |
In hold: 1.388 On deck: 1.398 Total:2.786 |
|
Number of 20ft containers |
In hold: 683 On deck: 1.398 Total: 1.358 |
|
Container capacity 14t |
2.221 |
|
Reefer capacity |
504 |
|
Length |
212,51 m overall 195,30 m between perpendiculars |
|
Breadth |
32,24 m extreme |
|
Draught |
12,50 m |
|
Depth |
20,30 m moulded |
|
Speed |
Max: 22,3 knots |
|
Built |
2011 |
|
Keel laid |
15/01/2011 |
|
Launch date |
17/04/2011 |
|
Date of completion |
12/08/2011 |
|
Builder |
Guangzhou Wenchong Shipyard Co., Ltd. Guangzhou China |
|
Yard number |
GWS405 |
|
Hull material |
Shipbuilding steel (Standard) |
|
Bulkheads |
7 |
|
Continuous decks |
1 |
|
Main engine |
1x Wärtsilä 8RT-flex68D - 2 stroke single acting 8 cylinder 680 x 2.720 mm combustion engine Mcr 25.040 kW / 30.044 hp at 95,0 rpm Manufacturer: Hudong Heavy Machinery Co Ltd - China |
|
Propellers |
1x Fixed pitch propeller - aft at 95,0 rpm |
|
Boilers |
Auxiliary boiler, oil/gas fired MISSION OS Auxiliary boiler, exhaust gas heated AV-4 |
|
Generators |
4x MAN-B&W 8L28/32H - 4 stroke 8 cylinder 280 x 320 mm diesel engines each Mcr 1.650 kW connected with generators each 1.600 ekW / 450 Volt |
|
Emergency generator |
1x Sisu 645 DSBAG diesel generatorset |
|
Bow thruster |
1x Tunnel thruster 1.200 kW / 1.632 bhp, forward |
|
Tank capacities |
Ballast: 12.772 m³ |
|
Anchor equipment |
Length: 660,00 m Diameter: 78 mm |
|
Cargo gear |
Gearless |
|
Commercial manager |
Hanse Bereederung GmbH Block B, 4th Floor, Anckelmannsplatz 1 20537 Hamburg Germany |
|
ISM Manager |
Columbia Shipmanagement Ltd. Columbia House, 21, Spyrou Kyprianou Avenue 4042 Limassol Cyprus |
|
Registered owner |
Cape Manila Navigation Co. Ltd. Care of Hanse Bereederungs GmbH Block B, 4th Floor, Anckelmannsplatz 1 20537 Hamburg Germany |
|
Renamed |
2022 Cul Manila Liberia, Monrovia - Call sign: 5FLW9 Owner: CUL Manila Shipping Limited Manager: Columbia Shipmanagement Ltd. |
|
Latest data adjustment |
20 February 2023 |
