| Antwerpen 11 December 2008 |
|
Name |
GULF BRIDGE |
|
Previous name |
Pontremoli |
|
Type |
Cellular Containership |
|
IMO-number |
9334519 |
|
Call sign |
A8JM5 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
GT |
Registered: 28.270 t Suez: 28.570,58 t |
|
DWT |
Summer: 32.971 t |
|
NT |
Registered: 13.327 t Suez: 22.114,98 t |
|
Number of 20ft contaers |
2.646 |
|
Container capacity at 14t |
2.010 |
|
Reefer capacity |
300 |
|
Length |
213,00 m overall 202,10 m between perpendiculars |
|
Breadth |
32,20 m overall |
|
Draught |
Summer: 10,50 m |
|
Freeboard |
5.035 mm |
|
Depth |
16,50 m moulded |
|
Speed |
Max.: 22,7 knots |
|
Built |
2006 |
|
Keel laid |
21.12.2004 |
|
Builder |
SML Jurong Shipyard Pte. Ltd. Republic of Singapore |
|
Yard number |
1077 |
|
Hull type |
Double hull |
|
Bulkheads |
Non Tight: 6 Water Tight: 22 Oil Tight: 2 |
|
Main engine |
1x MAN-B&W 7K80MC-C - 7 cylinder 800 x 2.300 mm engine - 25.270 kW at 104,0 rpm Manufacturer: Hitachi Zosen Diesel & Engineering Co. |
|
Propeller |
1x Manufacturer: Nakashima |
|
Boiler |
1x Auxiliary composite boiler AQ-10-16W - 9,0 bar Manufacturer: Aalborg Industries Ltd. |
|
Generators |
4x Taiyo FE553D main diesel generatorsets each 1.587 kW Manufacturer: Taiyo |
|
Hold capacity |
50.846 m³ |
|
Tank capacities |
Diesel oil: 435,2 0 m³ / 391,68 t Freshwater: 563,30 m³ / 563, 30 t Fuel oil: 3.898,20 m³ / 3.800,316 t Lube oil capacity: 395,90 m³ / 356,31 t Water ballast: 10.311,10 m³ / 10.568,8775 t |
|
Number of tanks |
Ballast: 19 Fuel Oil: 18 Lubricating Oil: 9 Fresh Water: 7 Diesel Oil: 5 Sludge: 5 Chain: 2 Waste Water: 1 Ammonia Waste: 1 |
|
Cargo gear |
Gearless |
|
Manager |
Reederei F. Laeisz GmbH |
|
Operator |
K-Line / Kawasaki Kisen Kaisha Line |
|
Owner |
Laeisz |
|
Registered owner |
MS Pontremoli GMBH & CO. KG |
