Name |
KONRAD SCHULTE |
|
Previous names |
2005 - 07/2009 Cap Maleas |
|
Type |
Cellular containership |
|
IMO-number |
9292125 |
|
Call sign |
P3ZA9 |
|
Flag |
Cyprus |
|
Port of registry |
Limassol |
|
GT |
18.334 t |
|
DWT |
Summer: 23.228 t |
|
NT |
10.287 t |
|
Number of 20ft containers |
In hold : 700 On deck: 1.036 1.736 |
|
Number of 40ft containers |
In hold: 388 On deck: 520 Total: 908 |
|
Container capacity 14t |
1.290 |
|
Reefer point |
300 reefer points (whereof 80 under deck) |
|
Length |
175,00 m overall |
|
Breadth |
27,40 m extreme |
|
Draught |
Max: 10,92 m |
|
Reg. dimensions L x B x D |
166,13 x 27,40 x 14,30 m |
|
Rule dimensions L x B x D |
165,00 x 27,40 x 14,30 m |
|
Keel to mast end |
51,29 m |
|
Freeboard |
Summer: 3.433 t |
|
Depth |
14,30 m |
|
Speed |
Max: 19,5 knots |
|
Built |
2005 |
|
Keel laid |
08/06/2004 |
|
Launch date |
25/09/2004 |
|
Date of completion |
03/01/2005 |
|
Builder |
Guangzhou Wenchong Shipyard Co. Ltd. Guangzhou China |
|
Yard number |
313 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Single hull double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
8 |
|
Continuous decks |
1 |
|
Main engine |
1x Hudong/MAN-B&W 7S60MC-C Mk 8 - 2 stroke 7 cylinder 600 x 2.400 mm combustion engine 15.785 kW at 105,0 rpm Built: 06/2004 Manufacturer: Hudong Heavy Machinery Co., Ltd., Shanghai - China |
|
Propellers |
1x Solid propeller (keyless) - aft at 105,0 rpm |
|
Boilers |
1x Steam boiler, oil fired / exhaust gas heated - 9,0 bar Heating surface: 61,0 m² Heating surface: 380,0 m² Built: 01/2004 Manufacturer: Kangrim Heavy Industrial Co., Ltd., Changwon - South Korea |
|
Generators |
3x MAN-B&W 6L28/32H main diesel generatorsets each 1.180 kW / 1.475 kVA - 450 Volt |
|
Emergency generator |
1x MAN D2866TE diesel generatorset 213 kVA |
|
Bow thruster |
1x Transverse thruster 900 kW |
|
Number of holds |
5 |
|
Cargo hold capacity |
27.172 m³ |
|
Number of hatches |
8 No. 1: 12,80 x 19,85 m No. 2: 12,84 x 24,93 m No. 3 - 8: 12,80 x 24,93 m |
|
Hatch type |
Pontoon hatch covers |
|
Tank capacities |
Fuel oil: 1.631,6 m³ Ballast water: 8.528,5 m³ Fresh water: 252,3 m³ |
|
Anchor equipment |
3x Anchors weight each 7.800 kg Chain length 632,50 m |
|
Lifting equipment |
1 Single crane - SWL 4,0 t 1 Single crane - SWL 6,0 t |
|
Cargo gear |
2x Single cranes, electro-hydraulic driven cranes - SWL 45,0 t each Outreach: 28,00 m |
|
Crew size |
30 |
|
Manager |
Bernhard Schulte Shipmanagement (Hellas) SPLLC 6-8 Kifissias Ave Maroussi, 15125 Greece |
|
Technical manager |
Bernhard Schulte Shipmanagement (Hellas) SPLLC |
|
Registered owner |
St Samuel Shipping Company Ltd. |
|
Renamed |
2021 Konrad Liberia: Monrovia - Call sign: 5LBI2 Owner: Kosova Shipping & Trading Co. Manager: Akar Deniz Tasimaciligi Ve Tic - Turkey ISM manager: Toba Ship Management Co Ltd. - Georgia |
|
Latest data adjustment |
14 Match 2023 |
