Westerschelde 06 January 2019 |
 |
 |
 |
 |
|||
| Westerschelde 06/01/19 | WS 06/01/19 | Westerschelde 05/11/18 | Westerschelde 23/05/17 | |||
|
Name |
ELBSAILOR |
|
Previous names |
2012 - 03/2013 Titian 03/2013 / 2017 E.R Visby |
|
Type |
Cellular containership |
|
IMO-number |
9448695 |
|
Call sign |
V2GY6 |
|
Flag |
Antigua & Barbuda |
|
Port of registry |
St. John’s |
|
Previous flags |
2012 - 2017 Liberia, Monrovia - Call sign: D5AT3 |
|
GT |
12.514 t |
|
DWT |
Summer: 14.236,33 t |
|
NT |
5.387 t |
|
Number of 20ft containers |
On deck: 728 In hold: 372 Total: 1.100 |
|
Container capacity 14t |
730 |
|
Reefer capacity |
On deck: 166 In hold: 84 Total: 250 |
|
Length |
157,93 m overall 148,50 m between perpendiculars |
|
Breadth |
23,78 m extreme 23,50 m moulded |
|
Draught |
Summer: 8,60 m |
|
Forecastle |
27,57 m |
|
Poop |
14,70 m |
|
Freeboard |
3.318 mm |
|
Speed |
Max: 18,3 knots |
|
Depth |
11,90 m |
|
Built |
2002 |
|
Keel laid |
18/08/2008 |
|
Launch date |
12/04/2010 |
|
Date of completion |
22/05/2012 |
|
Builder |
Nanjing Wujiazui Shipbuilding Co., Ltd. Dongjiangcun Baguazhou Zhen, Qixia Qu Nanjing, 210043 Jiangsu People's Republic of China |
|
Yard number |
WJZ025 |
|
Hull material |
Shipbuilding steel (standard) Higher tensile steel |
|
Hull type |
Double bottom |
|
Watertight bulkheads |
7 |
|
Continuous decks |
1 |
|
Main engine |
1x Wärtsilä 6RT-flex50B - 2 stroke 6 cylinder 500 x 2.050 mm combustion engine 9.960 kW / 13.545 bhp at 124,0 rpm Year of manufacture: 2008 Manufacturer: Hitachi Zosen Corporation, Ariake Machinery Works 1, Ohaza Ariake, Nagasu-machi Tamana-Gun, 869-0113 Kumamoto-ken Japan |
|
Propellers |
1x Controllable pitch propeller - aft at 124,0 rpm |
|
Boilers |
1x Steam boiler, oil fired - 9,0 bar Heating surface: 15,0 m² 1x Steam boiler, exhaust gas heated - 9,0 bar Heating surface: 193,0 m² Year of manufacture: 2009 Manufacturer: Alfa Laval Qingdao Ltd. 86 Guangzhou Road North Jiaozhou Qingdao, 266300 Shandong People's Republic of China |
|
Electric installations |
3x Plants each 450 V - 1.250 kVA 1x Plant 450 V - 124 kVA 2x Plants each 12 V - 90 Ah 2x Plants each 12 V - 195 Ah 4x Plants each 12 V - 195 Ah |
|
Generators |
3x Yanmar 8N21AL-SV main diesel generatorsets each 1.250 kVA - 1.000 kW - 1.495 hp |
|
Emergency generator |
1x MAN D0824 LE 201 diesel generatorset 124 kVA |
|
Batteries |
4x Batteries for other purpose each 195 Ah 2x Batteries for automation each 195 Ah 2x Batteries for start emergency engine each 90 Ah |
|
Compressed air receivers |
2x Receivers each 1.500 litres - 33,0 bar 1x Receiver 250 litres - 33,0 bar 1x Receiver 1.000 litres - 11,0 bar |
|
Bow thruster |
1x Transverse thruster 700 kW, forward |
|
Number of holds |
4 |
|
Total capacity of holds |
20.081,1 m³ |
|
Tank capacities |
Ballast: 5.672,7 m³ |
|
Anchor equipment |
3x Anchors weight each 6.000 kg Chain length: 577,50 m Diameter: 60 mm |
|
Cargo gear |
Gearless |
|
Crew size |
20 |
|
Manager |
USC Barnkrug GmbH & Co. KG Am Elbdeich 76 21706 Drochtersen Germany |
|
Previous names & managers |
2012 - 2013 Titian - Schiffahrtsgesellschaft mbH & Co KG ( Ernst Komrowski Reederei GmbH & Co KG Hamburg as manager ) Hamburg - Germany 2013- 2017 E.R. Visby - Zwolfte Kehrweiter Beteiligung GmbH Cia KG (E.R.Schiffahrtts GmbH & Co KG Hamburg as manager) Hamburg - Germany 2017 Elbsailor - Elbdeich Bereederungs GmbH, 21706 Drochtersen - Germany |
|
Registered owner |
MS "ELBSAILOR" GmbH & Co. KG Germany |
|
Group |
USC- United Shipping Companies |
|
Previous owner |
MS ''Elblifter'' GmbH & Co. KG, Drochtersen - Germany |
|
Latest data adjustment |
28 June 2023 |
