Westerschelde 13 October 2017 |
 |
 |
 |
 |
|||
| Westerschelde 03/07/18 | Westerschelde 03/07/18 | Westerschelde 11/08/19 | Westerschelde 11/08/19 | |||
|
Name |
ELBSTRAND |
|
Previous names |
2002 - 06/2004 Rachel Borchard 06/2004 - 05/2010 Nathalie Ehler 08/2010 - 06/2011 WEC Van Ruysdael 06/2011 - 06/2012 Nathalie Ehler 06/2012 - 11/2012 Ruth Borchard |
|
Type |
Container ship - Small feeder |
|
IMO-number |
9242560 |
|
Call sign |
V2GC4 |
|
Flag |
Antigua & Barbuda |
|
Port of registry |
St. John’s |
|
GT |
9.981 t |
|
DWT |
Summer: 11.367 t |
|
NT |
6.006 t |
|
Number of 20ft containers |
In hold: 601 On deck: 267 Total: 868 |
|
Container capacity 14t |
600 |
|
Reefer capacity |
150 |
|
Length |
134,44 m overall 124,41 m between perpendiculars |
|
Breadth |
22,74 m extreme 22,50 m moulded |
|
Draught |
8,71 m |
|
Freeboard |
2.609 mm |
|
Depth |
11,30 m |
|
Speed |
Service: 18,5 knots Max: 21,0 knots |
|
Built |
2002 |
|
Keel laid |
12/12/2000 |
|
Launch date |
09/02/2002 |
|
Date of completion |
01/03/2002 |
|
Builder casco |
Daewoo-Mangalia Heavy Industries S.A. - Mangalia Romania Yard number: 4020 |
|
Builder |
J.J. Sietas KG Schiffswerft GmbH & Co. Neuenfelder Fährdeich 88 21129 Hamburg Federal Republic of Germany Yard number: 1144 |
|
Hull material |
Shipbuilding steel (higher tensile) |
|
Hull type |
Single hull, double bottom |
|
Watertight bulkheads |
7 |
|
Number of decks |
1 |
|
Main engine |
1x MaK 9M43 - 4 stroke single acting 9 cylinder 430 x 610 mm combustion engine 8.400 kW / 11.413 hp at 500 rpm Built: 08/11/2006 Builder: Caterpillar Motoren GmbH & Co. KG; Kiel - Germany |
|
Propellers |
1x Screw propeller controllable pitch - aft at 130 rpm |
|
Boilers |
1x Thermal oil heater, oil fired - 10,0 bar Heating surface: 52,0 m² 1x Thermal oil heater, exhaust gas heated - 10,0 bar Heating surface: 208,0 m² Year of manufacture: 2001 Manufacturer: PWT Prozesswärmeträgertechnik GmbH Max-Weber-Str. 10 25451 Quickborn Federal Republic of Germany |
|
Electric installations |
2x Plants each 380/220 V - 625 kVA 1x Plant 380 V - 1.625 kVA 1x Plant 380 V - 290 kVA 1x Plant 24 V - 140 Ah 1x Plant 24 V - 240 Ah |
|
Shaft generator |
1x 1.625 kVA - 1.300 kW |
|
Generators |
2x Caterpillar 3412 - 4 stroke 12 cylinder 137 x 152 mm diesel engines each 650 kW / 726 hp connected with 2 generators each 625 kVA |
|
Emergency generator |
1x Main diesel generatorsets 290 kVA - 232 kW - 726 hp |
|
Batteries |
2x Batteries for start emergency engine each 140 Ah |
|
Compressed air receivers |
2x Receivers each 750 litres - 30,0 bar |
|
Bow thruster |
1x Transverse thruster Brunvoll - 750 kW / 1.020 bhp, forward 1x Transverse thruster Brunvoll - 450 kW - 612 bhp, aft |
|
Cargo hold capacity |
Grain: 4.730 m³ |
|
Tank capacities |
Fuel oil: 920 m³ Ballast water: 4.033 m³ |
|
Anchor equipment |
3x Anchors weight each 5.250 kg Length: 577,50 m Diameter: 56 mm |
|
Cargo gear |
Gearless |
|
Crew size |
12 |
|
Manager |
Reederei Heinz Ehler Beteiligungsgesellschaft mbH |
|
Owner |
MS "Elbstrand" GmbH & Co. KG |
|
Registered owner |
Nathalie Shipping Co. Ltd. |
|
Renamed |
2019 Amelie Borchard Antigua & Barbuda, St. John’s - Call sign: V2GC4 Manager: USC Barnkrug GmbH & Co. KG Owner: Elbstrand GmbH & Co KG |
|
Latest data adjustment |
08 June 2020 |
