Westerschelde 30 November 2018 |
 |
 |
|
| Westerschelde 02/01/19 | Westerschelde 05/07/18 |
|
Name |
FESCO ASKOLD |
|
Previous names |
2006 build as: Fesco Askold 05/2006 - 03/2009 Delmas Filao |
|
Type |
Cellular containership |
|
IMO-number |
9324942 |
|
Call sign |
C4JA2 |
|
Flag |
Cyprus |
|
Port of registry |
Limassol |
|
GT |
9.957 t registered |
|
DWT |
Summer: 13.806,2 t |
|
NT |
5.032 t registered |
|
Number of 20ft containers |
In hold: 334 On deck: 771 Total: 1.105 |
|
Container capacity 14t |
700 |
|
Reefer capacity |
220 |
|
Length |
147,87 m overall 140,30 m between perpendiculars 141,37 m registered |
|
Breadth |
23,25 m overall |
|
Draught |
Max: 8,51 m |
|
Keel to mast end |
45,20 m |
|
Forecastle |
11,70 m |
|
Poop |
13,30 m |
|
Freeboard |
2.990 mm |
|
Depth |
11,50 m |
|
Speed |
Max: 19,6 knots |
|
Built |
2006 |
|
Keel laid |
06/12/2004 |
|
Launch date |
07/11/2005 |
|
Date of completion |
20/04/2006 |
|
Builder |
China Changjiang National Shipping Group Nanjing Jinling Shipyard 55, Yanjiang Road 210015 Nanjing, Jiangsu People's Republic of China |
|
Yard number |
JLZ040-405 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Single hull Double bottom |
|
Number of bulkheads |
8 |
|
Continuous decks |
1 |
|
Main engine |
1x MAN-B&W 7L58/64 - 4 stroke single acting 7 cylinder 580 x 640 mm combustion engine output 9.730 kW / 13.229 hp at 428 rpm Year of manufacture: 2005 Builder: MAN Group Munchen Stadtbachstr. 1 86153 Augsburg Federal Republic of Germany |
|
Propellers |
1x Controllable pitch propeller - 4 blades |
|
Boilers |
1x Thermal oil heater, exhaust gas heated - 10,0 bar Heating surface: 98,8 m² 1x Thermal oil heater, oil fired - 13,0 bar Heating surface: 28,0 m² Year of manufacture: 2005 Manufacturer: Aalborg Industries Ltd. 1485-1 Ja-dong, Haeundae-gu 5th Floor, Saesam Building Busan Republic of Korea |
|
Electric installations |
1x 450/230 V - 2.139 kVA 1x 450 V - 1.750 kVA 1x 450 V - 687,5 kVA 1x 24 V - 640 Ah |
|
Shaft generator |
1.750 kVA / 1.400 kW |
|
Generators |
3x Main diesel generatorsets each 713 kVA / 570,4 kW |
|
Emergency generator |
1x Diesel generatorset 687,5 kVA / 550 kW |
|
Batteries |
2x Batteries for emergency lighting each 120 Ah |
|
Compressed air receivers |
2x Receivers each 1.250 litres - 30,0 bar |
|
Bow thruster |
1x Transverse thruster - 700 kW, forward |
|
Number of holds |
6 |
|
Cargo hold capacities |
Hold 1: 1.062 m³ Hold 2: 1.899 m³ Hold 3: 5.329 m³ Hold 4: 5.525 m³ Hold 5: 2.253 m³ Hold 6: 2.280 m³ |
|
Number of hatches |
5 1x 14,00 x 10,40 m 4x 12,60 x 18,00 m |
|
Tank capacities |
Fuel oil: 1.361,32 t MDO: 226,10 t Water ballast: 5.069 m³ |
|
Anchor equipment |
3x Anchors weight each 6.000 kg Chain length: 577,50 m |
|
Cargo gear |
2x Electro-hydraulic deck cranes - SWL 45,0 t each |
|
ISM & commercial manager |
Far-Eastern Shipping Company (FESCO) Plc. Office 338, 3rd Floor, Building 1, ul Novokuznetskaya 7/11 Moscow, 115184 Russia |
|
Registered owner |
Astro-Moon Shipping Co., Ltd., Limassol - Cyprus Care of Far-Eastern Shipping Company Plc (FESCO) (Dalnevostochnoye Morskoye Parokhodstvo) Office 338, 3rd Floor, Building 1, ul Novokuznetskaya 7/11, Moscow, 115184 Russia |
|
Latest data adjustment |
14 November 2021 |
