| Zeebrugge 04 July 2013 |
|
Name |
FENJA |
|
Previous names |
2003 - 10.2010 Aura - M.S. "Aura" Schiffahrtsges mbH. & Co., KG - Germany |
|
Type |
Container feeder |
|
IMO-number |
9287716 |
|
Call sign |
PHHT |
|
Flag |
The Netherlands |
|
Port of registry |
Heerenveen |
|
GT |
7.519 t |
|
DWT |
8.658 t |
|
NT |
3.570 t |
|
Number of 20ft containers |
In hold: 226 On deck: 596 Total: 822 |
|
Container capacity 14t |
509 |
|
Reefer capacity |
150 (380 V / 50 Hz 3 phases female) |
|
Length |
136,30 m overall 126,42 m registered |
|
Breadth |
21,30 m moulded 21,50 m overall |
|
Draught |
Summer: 7,47 m |
|
Forecastle |
9,04 m |
|
Poop |
27,19 m |
|
Depth |
9,36 m moulded |
|
Speed |
19,0 knots |
|
Built |
2003 |
|
Keel laid |
20.06.2002 |
|
Launch date |
25.10.2003 |
|
Date of completion |
18.12.2003 |
|
Builder |
J.J. Sietas KG Schiffswerft GmbH & Co. |
|
Yard number |
1218 |
|
Hull material |
Shipbuilding steel (higher tensile) |
|
Hull type |
Double bottom |
|
Watertight bulkheads |
7 |
|
Continuous decks |
2 |
|
Main engine |
1x MaK 9 M 43 - 4 stroke 9 cylinder 430 x 610 mm diesel engine - 8.400 kW at 514 rpm Reduced power: 7.850 kW Year of manufacture: 2003 Manufacturer: Caterpillar Motoren GmbH & Co. KG |
|
Propellers |
1x Controllable pitch propeller - aft at 137 rpm |
|
Boilers |
Thermal oil heater, oil fired - 10,0 bar Heating surface: 51,7 m² Thermal oil heater, exhaust gas heated - 10,0 bar Heating surface: 212,0 m² Year of manufacture: 2003 Manufacturer: PWT Prozess-Wärmeträgertechnik GmbH |
|
Electric installations |
2x Plants each 380/220 V - 625 kVA 1x Plant 380 V - 1.625 kVA 1x Plant 380 V - 290 kVA 1x Plant 24 V - 140 Ah 1x Plant 400 V - 16 kVA |
|
Shaft generator |
1x Piller 1.125 kVA / 1.300 kW |
|
Generators |
2x Caterpillar type 3412 - each 534 kW main diesel engine coupled with 2 Piller generators each 600 kVA |
|
Emergency generator |
1x Diesel generatorset 290 kVA |
|
Batteries |
2x Batteries for start emergency engine each 140 Ah |
|
Compressed air receivers |
2x Receivers each 750 litres - 30,0 bar 1x Receiver 500 litres - 11,0 bar |
|
Bow thruster |
1x Transverse thruster BRUNVOLL - 750 kW, forward |
|
Number of holds |
4x Box holds, steel floored Hold 1: 12,60 x 13,05 m Hold 2: 12,70 x 18,26 m Hold 3&4: 25,40 x 18,26 m |
|
Number of hatches |
6 |
|
Hatch type |
Hydraulic folding steel covers |
|
Max. permitted loads |
Tanktop: 7,0 t/m² Weather deck: 1,75 t/m² |
|
Hold ventilation |
6x Mechanical per hour |
|
Tank capacities |
Diesel oil: 120 t Fuel oil: 410 t Water ballast: 3.000 t Fresh water: 85 t |
|
Anchor equipment |
3x Anchors weight each 4.890 kg Chain length: 550,00 m |
|
Cargo gear |
None |
|
Crew |
11 |
|
Manager |
Holwerda Shipmanagement B.V. |
|
Registered owner |
Scheepvaartonderneming "FENJA" B.V. |
|
Last update |
23 July 2013 |
