| Zeebrugge 14 October 2011 |
|
Name |
KRISTIN SCHEPERS |
|
Type |
Cellular containership |
|
IMO-number |
9404089 |
|
Call sign |
5BPU2 |
|
Previous call sign |
V2HS4 |
|
Flag |
Cyprus |
|
Previous flag |
Antigua & Barbuda |
|
Port of registry |
Limassol |
|
Previous port of registry |
St. John's |
|
GT |
7.852 t |
|
DWT |
9.313 t |
|
NT |
3.363 t |
|
Number of 20ft containers |
803 |
|
Container capacity 14t |
517 |
|
Reefer containers |
180 |
|
Length |
140,53 m overall 130,60 m registered |
|
Breadth |
21,80 m registered |
|
Draught |
Summer: 7,335 m |
|
Depth |
9,50 m moulded |
|
Speed |
Service: 18,3 knots |
|
Built |
2008 |
|
Keel laid |
30.03.2006 |
|
Launch date |
11.12.2007 |
|
Date of completion |
05.06.2008 |
|
Builder |
Santierul Naval Damen Galati S.A. |
|
Yard number |
8303 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Double bottom |
|
Watertight bulkheads |
5 |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 9M43C - 4 stroke 9 cylinder 430 x 610 mm diesel engine - 8.400 kW at 500 rpm Year of manufacture: 2007 Manufacturer: Caterpillar Motoren GmbH & Co. KG |
|
Propeller |
1x Controllable pitch propeller - aft at 140 rpm |
|
Boilers |
1x Thermal oil heater, oil fired - 13,0 bar Heating surface: 28,0 m² Year of manufacture: 2006 Manufacturer: Alfa Laval Aalborg A/S 1x Thermal oil heater, exhaust gas heated - 10,0 bar Heating surface: 126 m² Year of manufacture: 2007 Manufacturer: TUBE-TEC Rohrverformungstechnik GmbH Federal Republic of Germany |
|
Electric installations |
1x Plant 450/230 V - 530 kVA 1x Plant 450/230 V - 530 kVA 1x Plant 450 V - 2.000 kVA 1x Plant 450 V - 268,75 kVA 1x Plant 24 V - 150 Ah 1x Plant 24 V - 200 Ah 1x Plant 24 V - 200 Ah 1x Plant 24 V - 230 Ah |
|
Shaft generator |
1x 1.600 kW / 2.000 kVA |
|
Generators |
2x Main diesel generatorsets each 420 kW / 525 kVA |
|
Emergency generator |
1x Diesel generatorset 215 kW / 268,75 kVA |
|
Batteries |
1x Battery for UPS navigation 230 Ah 2x Batteries for start emergency engine each 200 Ah 1x Battery for UPS radio 200 Ah |
|
Compressed air receivers |
2x Receivers each 1.000 litres - 30,0 bar 1x Receiver 500 litres - 11,0 bar |
|
Thrusters |
1x Transverse thruster - 700 kW, forward 1x Transverse thruster - 500 kW, aft |
|
Number of hatches |
3 |
|
Anchor equipment |
3x Anchors weight each 4.890 kg Chain Length: 550,00 m |
|
Cargo gear |
None |
|
Crew size |
15 |
|
Crew |
13 |
|
Manager |
HS Schiffahrts GmbH & Co. KG |
|
Operator |
Unifeeder "De Blaker", Westblaak 7F |
|
Owner |
HS Schiffahrts GmbH & Co. KG MS ''KRISTIN SCHEPERS'' |
