Name |
SEASPAN GANGES |
|
Previous names |
2014 - 2016 Hanjin Buddhja |
|
Type |
Cellular containership |
|
IMO-number |
9630365 |
|
Call sign |
VRMV8 |
|
Flag |
Hong Kong - China |
|
Port of registry |
Hong Kong |
|
GT |
113.042 t |
|
DWT |
Summer: 115.177 t |
|
NT |
57.162 t |
|
Number of 20ft containers |
10.000 |
|
Length |
336,95 m overall 319,96 m between perpendiculars |
|
Breadth |
48,19 m moulded 48,31 m extreme |
|
Draught |
15,22 m |
|
Depth |
27,20 m |
|
Speed |
Service: 23,0 knots |
|
Built |
2014 |
|
Keel laid |
16/04/2013 |
|
Launch date |
25/09/2013 |
|
Date of completion |
20/03/2014 |
|
Builder |
Jiangsu New Yangzijiang Shipbuilding Co., Ltd. |
|
Yard number |
YZJ2011-983 |
|
Hull material |
Steel |
|
Main engine |
1x MAN-B&W 10S90ME-C9 - 10 cylinder combustion engine 78.993 bhp / 58.100 kW |
|
Propellers |
1x Fixed propeller - 6 blades Builder: Nakashima Propeller CO. Ltd. |
|
Boilers |
Auxiliary boiler, exhaust gas heated (XS-7V, Exhaust) Auxiliary boiler, oil/gas fired (AOC-TCi, oil fired) - Mission OS-TCi-5500 Builder: Alfa Laval Aalborg A/S |
|
Generators |
2x Daihatsu 8DC-32 diesel generatorsets each 3.690 kW 2x Daihatsu 6DC-32 diesel generatorsets each 2.648 kW |
|
Emergency generator |
1x Doosan diesel generatorset |
|
Tank capacities |
Ballast: 31.530,4 m³ |
|
Anchor equipment |
Length: 770,00 m Diameter: 114 mm |
|
Cargo gear |
Gearless |
|
Manager |
Seaspan Shipmanagement Ltd. |
|
Owner |
Seaspan Container Line |
|
Registered owner |
Seaspan YZJ 983 Ltd. |
|
Previous owners |
2014 - 2014 Seaspan Corporation |
|
Latest data adjustment |
17 January 2020 |
