Westerschelde 08 June 2020 |
 |
 |
 |
 |
 |
||||
| Westerschelde 17/04/20 | Westerschelde 16/03/20 | Westerschelde 14/03/20 | Westerschelde 10/10/18 | Westerschelde 17/05/18 | ||||
|
Name |
HAPPY AVOCET |
|
Type |
Liquefied gas tanker - Ethylene Carrier - LPG/C |
|
IMO-number |
9694373 |
|
Call sign |
OXMY2 |
|
Flag |
Denmark |
|
Port of registry |
København |
|
Previous flag |
Republic of Panama, Panama City - Call sign: 3EVZ3 |
|
GT |
13.549 t |
|
DWT |
Summer: 15.075,4 t |
|
NT |
4.065 t |
|
Length |
146,20 m overall 138,79 m between perpendiculars |
|
Breadth |
22,62 m extreme |
|
Draught |
Max: 9,31 m |
|
Keel to mast end |
40,12 m |
|
Depth |
12,10 m moulded |
|
Speed |
Max: 15,0 knots |
|
Built |
2017 |
|
Keel laid |
09/12/2015 |
|
Date of completion |
10/02/2017 |
|
Builder |
STX Offshore & Shipbuilding Co., Ltd. Gyeongsangnam-do South Korea |
|
Yard number |
4034 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Number of decks |
1 |
|
Main engine |
1x MAN-B&W/STX 6S40ME-B9 - 2 stroke 6 cylinder 400 x 1.770 mm combustion engine 5.788 kW / 7.788 hp at 146,0 rpm |
|
Propellers |
1x Controllable pitch propeller |
|
Generators |
3x STX MAN Holeby 6L21/31 main diesel generatorsets |
|
Bow thruster |
1x 690 kW |
|
Number of cargo tanks |
3 |
|
Cargo tank capacity |
Tank 1: 4.060,5 m³ Tank 2: 4.060,5 m³ Tank 3: 4.060,5 m³ |
|
Deck tank capacity |
156,8 m³ |
|
Cargo pumps |
3x Svanehoy cargo pumps each 400 m³/h |
|
Pressure |
5,5 bar |
|
Min temperature |
-104°C |
|
Lifting equipment |
1x Crane - SWL 4,0 t - midship |
|
Manager |
Navigator Gas Ship Management (Denmark) ApS Smakkedalen 4 2820 Gentofte Denmark |
|
Operator |
Unigas International B.V. 6th Floor, Grotiushuis, Westblaak 41 3012 Kd Rotterdam The Netherlands |
|
Registered owner |
Falstria Shipping Company SA 6, Smakkedalen Gentofte 2820 Denmark |
|
Latest data adjustment |
11 February 2023 |
