Name |
HAPPY BEAR |
|
Previous names |
1997 - 16/09/2002 Tarquin Brae 16/09/2002 - 10/05/2004 Elise Schulte 10/05/2004 - 05/12/2010 Pacificgas |
|
Type |
Liquefied gas tanker - Semi refrigerated |
|
IMO-number |
9131096 |
|
Call sign |
2EAA9 |
|
Flag |
Isle of Man - United Kingdom |
|
Previous flags |
1997 - 2002 Liberia, Monrovia 2002 - 2004 Isle of Man, Douglas 2004 - 2008 Chili 2008 - 2010 Republic of Panama, Panama City |
|
Port of registry |
Douglas |
|
GT |
5.420 |
|
DWT |
Summer: 7.246 t |
|
NT |
2.019 |
|
Length |
113,60 m overall 106,90 m between perpendiculars |
|
Breadth |
16,54 m |
|
Draught |
Summer: 7,61 m |
|
Keel to mast end |
32,90 m |
|
Depth |
8,75 m |
|
Speed |
15,6 knots |
|
Built |
1997 |
|
Date of completion |
14/02/1997 |
|
Builder |
Hyundai Heavy Industries Co., Ltd. Ulsan South Korea |
|
Hull type |
Double hull |
|
Main engine |
1x MAN-B&W/Hyundai 6S5MC - 2 stroke 6 cylinder 350 x 1.400 mm combustion engine 3.780 kW / 5.139 bhp at 173,0 rpm |
|
Propeller |
1x Controllable pitch propeller |
|
Generators |
3x Cummins VTA 28G5M diesel generatorsets each 550 kW |
|
Bow thruster |
1x Brunvoll controllable pitch thruster - 300 KW |
|
Cargo capacity |
7.304 m³ |
|
Number of tank |
2 |
|
Tank capacity 100% |
Tank 1: 3.434,81 m³ Tank 2: 3.869,08 m³ Total: 7.303,88 m³ |
|
Max. pressure |
6,5 bar |
|
Min. temperature |
-48°C |
|
Cargo pumps |
4x Svanehoy each 225 m³/h at 120 mlc max.: SG = 970 kg/m³ |
|
Cargo refrigeration |
1x Sulzer type 2k - 160 - 2 H - 1.136 m³/h 1x Sulzer type 3K - 140 - 3A - 1.250 m³/h |
|
Lifting equipment |
1x Hose cranes - SWL 2,0 t 1x Hose cranes - SWL 4,0 t |
|
Crew |
20 |
|
Owner |
East River Marine SA |
|
Previous names & operators |
1997 Tarquin Brae - Liquid Gas (Isle of Man) Ltd. 2002 Elise Schulte - Injebreck Shipping Ltd. 2004 Pacificgas - Ultragas Navieta Ltd. |
|
Sister ships |
05/1997 Happy Bee - IMO 9143506 03/1997 Jotagas - IMO 9131101 |
|
Renamed |
2019 Bright Honor Republic of Panama, Panama City - Call sign: 3FGL4 Owner: Golden Pioneer Shipping Co., Ltd. - China Manager: WS Shipping Co,. Ltd. - China 2023 G Jades Republic of Panama, Panama City - Call sign: 3FGL4 Owner: JLS Ship No 13 Co., Ltd. - Hong Kong Operator: Ultraship Aps |
|
Latest data adjustment |
06 January 2024 |
