Westerschelde 08 February 2020 |
 |
 |
|
| Westerschelde 13/10/19 | Westerschelde 13/02/20 | |
|
Name |
KINGCRAFT |
|
Type |
Liquefied gas tanker - LPG |
|
IMO-number |
9713648 |
|
Call sign |
9V2737 |
|
Flag |
Republic of Singapore |
|
Port of registry |
Singapore City |
|
GT |
8.359 t |
|
DWT |
8.982 t |
|
NT |
2.940 t |
|
Displacement |
Laden: 14.181 t Light: 7.199 t |
|
Length |
119,98 m overall 114,00 m between perpendiculars |
|
Breadth |
21,02 m extreme |
|
Draught |
Summer: 7,31 m |
|
Distance bow to bridge |
97,60 m |
|
Keel to highest point |
33,95 m |
|
Air draft |
28,80 m normal ballast |
|
Freeboard |
2.716 m |
|
Depth |
10,01 m moulded |
|
Speed |
Service: 14,8 knots Max: 16,9 knots |
|
Built |
2015 |
|
Keel laid |
05/04/2015 |
|
Delivery date |
29/10/2015 |
|
Builder |
Kyokuyo Shipbuilding & Iron Works 8-7 Minato-Machi Chofu Shimonoseki City, 752-0953 Japan |
|
Yard number |
520 |
|
Hull material |
Mild steel |
|
Hull type |
Double side |
|
Main engine |
1x Hitachi/MAN-B&W 6S35ME-B9.3 - 2 stroke single acting 6 cylinder 350 x 1.550 mm combustion engine 5.220 kW / 7.097 bhp at 167 rpm Manufacturer: Hitachi Zosen Corporation Innoshima Works - Japan |
|
Propellers |
1x Fixed pitch propeller 4 blades solid high skewed type |
|
Boilers |
1x Composite boiler - 6,9 MPa |
|
Generators |
3x 6N165L-EW main diesel diesel engine each 530 kW connected with generators each 480 kW |
|
Number of cargo tanks |
2x Independent tank |
|
Cargo tank capacity |
Tank 1: 100%: 5.512,198 m³ 98%: 5.401,954 m³ Tank 2: 100%: 5.511,590 m³ 98%: 5.401,358 m³ Total: 100%: 11.023,788 m³ 98%: 20.803,312 m³ |
|
Number of pumps |
4x Wartsila Svanehoj cargo pumps each 300 m³/h 2x Ballast pumps each 250 m³/h |
|
Min temp |
-10°C |
|
Max pressure |
17,65 bar |
|
Manifolds |
Distance bridge front to mid-point manifold: 42,00 m Distance bow to mid-point manifold: 55,60 m Distance of manifold above deck: 1,16 m Distance of manifold from ship's side: 3,50 m Distance of manifold above waterline summer: 6,91 m |
|
Tank capacities |
Diesel oil: 159,88 m³ Lub oil: 11,03 m³ Ballast: 3.527,51 m³ Fresh water: 195,49 m³ Fuel oil: 703.25 m³ |
|
Lifting equipment |
1x Hose handling crane - SWL 5,0 t Manufacturer: Mansei Inc. 1x Provision crane - SWL 1,0 t Manufacturer: Okamoto Iron Works Co., Ltd. |
|
Crew |
24 |
|
Operator |
Anglo-Eastern Shipmanagement (S) Pte Ltd. Republic of Singapore |
|
Registered owner |
Kingcraft Shipping Pte. Ltd. |
|
Renamed |
11/2020 Epic Sunter Republic of Singapore, Singapore City - Call sign: 9V2737 Owner: Epic Gas Echo Pte Ltd.- Republic of Singapore Manager: BW Epic Kosan Maritime Pte. Ltd. - Republic of Singapore |
|
Latest data adjustment |
22 November 2023 |
