Norgas Alameda - IMO 9240158

Name

NORGAS ALAMEDA

Type

Liquefied gas tanker

IMO-number

9240158

Call sign

VRYJ2

Flag

Republic of Singapore

Port of registry

Singapore City

GT

8.720 t

DWT

9.265 t

NT

2.617 t

Light displacement

4.939 t

Length

124,90 m overall

115,00 m between perpendiculars

Breadth

19,80 m

Draught

Summer: 8,30 m

Keel to mast end

37,70 m

Depth

11,50 m

Speed

Max: 16,5 knots

Service: 12,0 knots

Build

2003

Keel laid

25/03/2002

Launch date

26/06/2002

Delivery date

28/04/2003

Builder

Hudong Zhonghua Shipbuilding Group

China

Yard number

432

Hull material

Steel

Continuous decks

1

Main engine

1x MAN-B&W 6L48/60 - 4 stroke 6 cylinder 480 x 600 mm combustion engine 6.300 kW / 8.565 hp at 500 rpm

Propellers

1x Controllable pitch propeller

Boilers

1x Thermal oil heater, oil fired - 10,0 bar

Heating surface: 56,5 m²

1x Thermal oil heater exhaust gas heated - 10,0 bar

Heating surface: 90,0 m²

Manufacturer: Aalborg Industries A/S, Aalborg - Denmark

Shaft generator

1x 1.800 kW

Generators

4x MAN D2842LE301 diesel generatorsets each 732 kW

Emergency generator

1xMAN D2866 E diesel generatorset 145 kW

Bow thruster

1x Brunvoll FU-63-LTC-155 - 705 kW, forward

Number of tanks

3

Cargo tank capacity

Liquid: 8.297 m³

Number of pumps

1x Booster pump 380 m³/h

1x Deepwell cargo pump 640 m³/h

Max pressure

7,0 bar

Min temp

-104°C

Manager

Norgas Carrier A/S

Oslo

Norway

Owner

Somargas Ltd.

Hong Kong

China

Renamed

08/2019 - 05/2003 Coral Alameda

Republic of Singapore, Singapore City - Call sign: 9V8458

Reg. owner: Alameda Shipping Co., Pte Ltd., Rotterdam - The Netherlands

Manager: Anthony Veder Rederij BV, Rotterdam - The Netherlands

12/05/2023 Lotus 6

Antigua and Barbuda, St John’s - Call sign: V2YG8

Owner/manager: HP Shipmanagement LLC - Sharjah - United Arab Emitrates

Latest data adjustment

15 October 2024
