| Westerschelde 30 September 2012 |
 |
| Zeebrugge 15/03/11 |
|
Name |
HAPPY GIRL |
|
Previous names |
1989 - 1995 Sunny Girl |
|
Type |
Liquefied gas tanker |
|
IMO-number |
8800298 |
|
Call sign |
2BXN4 |
|
Previous call sign |
LARE5 |
|
Flag |
Isle of Man |
|
Previous flag |
1989 - 2001 Philippines Norway |
|
Port of registry |
Douglas |
|
Previous port of registry |
Stavanger |
|
GT |
3.643 t |
|
DWT |
4.248 t |
|
NT |
1.104 t |
|
Length |
98,30 m overall 90,97 m between perpendiculars |
|
Breadth |
15,37 m |
|
Draught |
Summer: 6,266 m |
|
Freeboard |
1.261 mm |
|
Depth |
7,50 m |
|
Speed |
15,1 knots |
|
Built |
1989 |
|
Keel laid |
04.10.1988 |
|
Launch date |
30.04.1989 |
|
Date of completion |
01.06.1989 |
|
Builder |
Hyundai Heavy Industries |
|
Yard number |
634 |
|
Hull type |
Single hull |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 6 M 551 - 4 stroke 6 cylinder 450 x 550 mm diesel engine - 3.309 kW / 4.496 hp at 450 rpm Built: 1988 Builder: MaK Motoren GmbH & Co. KG, Kiel - Germany |
|
Propelling system |
1x Screw propeller controllable pitch |
|
Boiler |
1x CHM OVEC 22,10 m² - 8,0 bar |
|
Generators |
4x Mercedes Benz OM404 V12 diesel generatorsets each 441 kVA - 353 kW - 512 hp |
|
Bow thruster |
1x CPP type Ulstein propeller - 230 kW |
|
Number of tanks |
2 |
|
Total capacity of tanks |
Tank 1: 1.922,959 m³ Tank 2: 2.111,530 m³ Total (100%): 4.034,489 m³ |
|
Pressure |
5,69 bar |
|
Temperature |
-103°C |
|
Cargo pumps |
4x Svanehoy, max. SG = 970 kg/m³ Capacity: 4x 150 m³/h at 120 mlc. |
|
Cargo refrigeration |
2x Sulzer type 2K 140-2F - 1.480 m³/h each |
|
Lifting equipment |
1x Crane - SWL 2,0 t 1x Crane - SWL 4,0 t |
|
Anchor chain |
Length: 419,5 m Diameter: 36 mm |
|
Fuel capacity |
364,5 m³ |
|
Crew |
16 |
|
Manager |
Bernhard Schulte Shipmanagement (Cyprus) Ltd. |
|
Operator |
Unigas |
|
Owner |
Lizard Shipping and Finance Inc. |
|
Previous owners |
1989 - 2001 Vigor Tankers Inc. |
|
Scrapped |
01.2014 Turkey |
