Westerschelde 02 July 2018 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 22/05/14 | Zeebrugge 13/05/12 | Zeebrugge 13/05/12 | Zeebrugge 25/03/14 | Westerschelde 23/10/15 | Westerschelde 25/06/20 |
|
Name |
MAGDALENA |
|
Type |
Liquefied gas tanker |
|
Main products |
Butane - Methyl-Acetylene-Propadiene mix - Ethylene - Liquefied petroleum gases - Propylene oxide - Vinyl-Chloride monomer |
|
IMO-number |
9434541 |
|
Call sign |
VRTN7 |
|
Flag |
Hong Kong - China |
|
Port of registry |
Hong Kong |
|
Previous flags |
Belgium, Antwerpen - Call sign: ONJX |
|
GT |
3.493 t |
|
DWT |
3.996 t |
|
NT |
1.048 t |
|
Length |
97,24 m overall 89,90 m between perpendiculars |
|
Breadth |
16,50 m |
|
Draught |
Summer: 5,41 m |
|
Keel to mast end |
31,09 m |
|
Freeboard |
1.817 mm |
|
Depth |
7,20 m |
|
Speed |
13,6 knots |
|
Built |
2008 |
|
Date of completion |
24/10/2008 |
|
Builder |
Yamanishi Shipbuilding & Iron Works Ishinomaki Japan |
|
Yard number |
1065 |
|
Hull material |
Mild Steel |
|
Hull type |
Double hull |
|
Watertight bulkheads |
6 |
|
Continuous decks |
1 |
|
Main engine |
1x Mitsubishi 5UEC33LSII - 2 stroke 5 cylinder 330 x 1.050 mm combustion engine 2.700 kW / 3.668 hp at 210 rpm Built: 08/05/2008 Builder: Akasaka Diesels Limited, Yaizu - Japan |
|
Propeller |
1x Screw propeller solid at 210 rpm |
|
Generators |
2x Diesel generatorsets each 500 kVA - 400 kW - 599 hp |
|
Emergency generator |
1x Diesel generatorset 50 kVA - 40 kW - 68 hp |
|
Number of tanks |
2 |
|
Total capacity of tanks |
Liquid: 3.541 m³ |
|
Tank max. pressure |
17,7 bar |
|
Minimum temperature |
-10°C |
|
Number of pumps |
2x cargo pumps each 300 m³/h |
|
Tank capacities |
Fuel capacity: 643 m³ |
|
Crew |
17 |
|
Manager |
Exmar De Gerlachekaai 20 2000 Antwerpen Belgium |
|
Previous manager |
Wah Kwong Ship Management (HK) Ltd. 25th Fl, Shanghai Industrial Investment Bldg, 48-62 Hennessy Rd, Wanchai Hong Kong China |
|
Operator |
Exmar |
|
Registered owner |
Hallsworth Marine Co. |
|
Latest data adjustment |
25 November 2021 |
