Westerschelde 11 June 2020 |
 |
 |
|
| Antwerpen 28/09/14 | Westerschelde 27/03/20 | |
|
Name |
GREENWICH PARK |
|
Previous names |
2011 - 02/2012 Sanko Neptune |
|
Type |
Oil / Chemical tanker |
|
IMO-number |
9505998 |
|
Call sign |
A8YZ9 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
GT |
11.987 t Suez: 12.617 t |
|
DWT |
Summer: 19.998,97 t Winter: 19.401 t |
|
NT |
6.193 t Panama: 10.081 t Suez: 10.995 t |
|
Displacement |
25.469 t |
|
Light ship |
5.497 t |
|
Length |
146,19 m |
|
Breadth |
24,20 m moulded |
|
Draught |
Summer: 9,53 m |
|
Moulded L x B x D |
138,10 x 24,20 x 12,90 m |
|
Registered L x B x D |
138,56 x 24,20 x 12,90 m |
|
Freeboard |
3.403 mm |
|
Depth |
12,90 m moulded |
|
Speed |
15,5 knots ballast 14,5 knots loaded |
|
Built |
2011 |
|
Keel laid |
28/10/2010 |
|
Launch date |
21/02/2011 |
|
Date of completion |
31/05/2011 |
|
Builder |
Fukuoka Shipbuilding Co. Ltd. Fukuoka Japan |
|
Yard number |
1287 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Number of decks |
1 |
|
Main engine |
1x MAN-B&W 6S42MC - 2 stroke single acting 6 cylinder 420 x 1.764 mm combustion engine 6.150 kW / 8.362 hp at 136,0 rpm Manufacturer: Hitachi Zosen Corporation Innoshima Works - Japan |
|
Propeller shaft |
1x Oil lubrication shaft without monitoring device Diameter: 430 mm |
|
Propellers |
1 |
|
Boilers |
1x Auxiliary vertical boiler - 9,3 bar Evaporation: 15,97 t/h Manufacturer: Tortoise Engineering Co., Ltd. |
|
Generators |
3x Yanmar 6EY18AL - 4 stroke 6 cylinder 180 x 280 mm diesel engine each 550 kW connected with generators each 500 kW - 450 Volt 60 Hz |
|
Bow thruster |
1x Tunnel thruster 633 kW / 860 bhp, forward |
|
Number of tanks |
20 |
|
Cargo tank capacity |
1P: 625 m³ 1S: 638 m³ 2P: 1.209 m³ 2S: 1.222 m³ 3P: 1.550 m³ 3S: 1.550 m³ 4P: 1.392 m³ 4S: 1.406 m³ 5P: 733 m³ 5S: 746 m³ 6P: 1.316 m³ 6S: 1.316 m³ 7P: 1.393 m³ 7S1.406 m³ 8P: 1.312 m³ 8S: 1.312 m³ 9P: 711 m³ 9S: 724 m³ 10P: 610 m³ 10S: 623 m³ Total: 21.803 m³ |
|
Segregations double valve separation |
20 |
|
Number of slop tanks |
2 |
|
Slop tank capacity |
1.233 m³ |
|
Cargo pumps |
12x Deepwell each 300 m³/h |
|
Manifolds |
Distance bow to centre of manifold: 73,34 m Distance deck to centre of manifold: 2,60 m Distance manifold to rail: 4,35 m |
|
Tank capacities |
Fuel oil: 1.058 m³ Fresh water: 996 m³ Water ballast: 6.900 m³ |
|
Manager |
Zodiac Maritime Limited 5th Floor, Portman House 2 Portman Street London, W1H 6DU United Kingdom |
|
Registered owner |
Sarquil Shipping Inc. Care of Zodiac Maritime Limited 5th Floor, Portman House 2 Portman Street London, W1H 6DU United Kingdom |
|
Latest data adjustment |
29 January 2023 |
