Westerschelde 12 June 2018 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 30/04/15 | Vlissingen 29/12/18 | Westerschelde 01/07/20 | Westerschelde 07/03/16 | Westerschelde 07/03/16 | Westerschelde 20/03/17 | |||||
|
Name |
JOAN |
|
Type |
Fully pressurized gas carriers - LPG |
|
Transport type |
Pressure |
|
IMO-number |
9448877 |
|
Belgian registration number |
02 00072 2019 |
|
Call sign |
ONJY |
|
Flag |
Belgium |
|
Port of registry |
Antwerpen |
|
Previous flag |
2009 - 2019 Hong Kong - China, Hong Kong - Call sign: VRFC6 |
|
GT |
3.493 |
|
DWT |
Summer: 3.999,78 t |
|
NT |
1.048 |
|
Length |
97,23 m overall 89,90 m between perpendiculars |
|
Breadth |
16,50 m extreme |
|
Draught |
5,41 m |
|
Keel to mast end |
31,07 m |
|
Freeboard |
1.817 mm |
|
Depth |
7,20 m |
|
Speed |
14,5 knots |
|
Built |
2009 |
|
Date of completion |
06/07/2009 |
|
Builder |
Yamanishi Corporation Ishinomaki Japan |
|
Yard number |
1078 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x MAN-B&W/Makita 5L35MC - 2 stroke 5 cylinder 350 x 1.050 mm combustion engine 2.700 kW / 3.668 hp at 210 rpm Build: 2009 Builder: Makita Corporation Takamatsu, Kagawa - Japan |
|
Propellers |
1x Fixed pitch propeller - aft at 210 rpm |
|
Shaft generator |
2x 500 kVA - 400 kW |
|
Number of cargo tanks |
2 |
|
Total capacity of tanks |
3.540 m³ |
|
Minimum temperature |
-10°C |
|
Number of pumps |
2x Cargo pumps each 300 m³/h |
|
Tank capacities |
Fuel oil: 643 m³ |
|
Commerical manager |
Exmar Marine SA De Gerlachekaai, 20 2000 Antwerpen Belgium |
|
ISM manager |
Exmar Shipmanagement NV De Gerlachekaai, 20 2000 Antwerpen Belgium |
|
Registered owner |
Exmar Small-Scale LPG NV Care of Exmar Marine SA De Gerlachekaai 20 2000 Antwerpen Belgium |
|
Previous owner |
Universal Crown Ltd. GAM SHIP004 Inc. |
|
Latest data adjustment |
21 October 2023 |
