Westerschelde 12 October 2018 |
 |
| Westerschelde 10/12/18 |
|
Name |
ARKLOW DAY |
|
Previous names |
06/2011 - 12/2016 Flinter Aland 12/2016 - 20/2017 Riga |
|
Type |
Multi-purpose dry carrier - Containership - Heavycargo |
|
IMO-number |
9504140 |
|
Call sign |
PDTV |
|
Flag |
The Netherlands |
|
Port of registry |
Rotterdam |
|
Previous flags |
2011 - 2017 The Netherlands, Rotterdam - Call sign: PCKY 2017 - 2020 Ireland, Arklow - Call sign: EITE2 |
|
GT |
6.687 t |
|
DWT |
Summer: 10.806 t Winter: 10.539 t |
|
NT |
3.448 t |
|
Number of 20ft containers |
356 |
|
Length |
132,50 m overall 126,35 m between perpendiculars |
|
Breadth |
15,87 m |
|
Draught |
Summer: 7,83 m Winter: 7,67 m Ballast: 4,40 m |
|
Air draft |
Min.: 34,40 m |
|
Freeboard |
2.955 mm |
|
Depth |
10,87 m moulded |
|
Speed |
14,1 knots |
|
Built |
2011 |
|
Launch date |
14/05/2011 |
|
Date of completion |
09/06/2011 |
|
Builder |
Scheepswerf Ferus Smit B.V. Westerbroek The Netherlands |
|
Yard number |
400 |
|
Hull material |
Steel |
|
Movable bulkheads |
3 |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 8M32 - 4 stroke single acting 8 cylinder 320 x 480 mm combustion engine 4.000 kW / 5.435 bhp at 600 rpm Built: 2010 Builder: Caterpillar Motoren GmbH & Co. KG, Kiel - Germany |
|
Propellers |
1x Screw propeller controllable pitch - aft at 159 rpm |
|
Shaft generator |
1x 850 kVA - 680 kW |
|
Generators |
2x Mitsubishi S6B3-NPTA diesel generatorsets each 388 kVA - 310 kW - 455 hp 1x Diesel generatorset 131 kVA - 105 kW - 455 hp |
|
Bow thruster |
1x Electric bow thruster 573kW |
|
Number of holds |
2 Hold 1: 32,50 x 13,20 x 10,62 m Hold 2: 64,00 x 13,20 x 10,62 m |
|
Total capacity of holds |
Grain / bale: Hold 1: 4.157,71 m³ / 146.828 ft³ Hold 2: 8.851,08 m³ / 312.573 ft³ Total: 13.008,79 m³ / 459.401 ft³ |
|
Hold ventilation |
6x Changes per hour in empty holds |
|
Hatch type |
Pontoon |
|
Max. permitted loads |
Tanktop: 15,0 t/m³ Hatch cover: 1,75 t/m² |
|
Tank capacities |
Fuel oil: 587,76 m³ |
|
Lifting equipment |
Gantry Crane fitted with two derricks |
|
Cargo gear |
Gearless |
|
Manager |
Arklow Shipping Nederland B.V. Rotterdam The Netherlands |
|
Previous managers |
06/2011 - 12/2016 Flinter Shipping BV., 2993 LV Barendrecht - The Netherlands 12/2016 - 10/2017 Management Facilities Group, Farmsum - The Netherlands 10/2017 - 10/2020 Arklow Shipping Ltd., Arklow - Ireland |
|
Owner |
Arklow Shipping Nederland B.V. Rotterdam The Netherlands |
|
Registered owner |
Kilbride Shipping Limited |
|
Previous owners |
06/2011 - 12/2016 Flinter Aland - Flinter Aland N.V., 2993 LV Barendrecht - The Netherlands 12/2016 - 10/2017 Riga - Flinter Aland N.V., Rotterdam - The Netherlands 10/2017 - 10/20020 Arklow Day - Arklow Shipping Ltd., Arklow - Ireland |
|
Renamed0 |
8/2022 Helme Cyprus, Limassol - Call sign: 5BBU6 Manager: Graanul Invest A.S., Tallinn (Reval) - Estonia Owner: Imavere Shipping Company Limited, Limassol - Cyprus |
|
Latest data adjustment |
28 September 2022 |
