Westerschelde 16 August 2019 |
Westerschelde 16/08/19 | Westerschelde 16/08/19 |
Name |
FULMAR S |
Previous names |
2007 - 2018 Diana |
Type |
Multi-purpose carrier - Heavycargo |
IMO-number |
9370082 |
Call sign |
8PAP6 |
Flag |
Barbados |
Port of registry |
Bridgetown |
Previous flags |
2007 - 2018 Antigua & Barbuda, St. John’s - Call sign: V2CM2 |
GT |
9.556 t |
DWT |
Summer: 13.450 t |
NT |
4.378 t |
Number of 20ft containers |
771 |
Reefer capacity |
300 |
Length |
138,07 m overall 130,00 m between perpendiculars |
Breadth |
21,00 m |
Draught |
Max: 8,38 m |
Freeboard |
2.633 mm |
Depth |
11,00 m |
Speed |
Max: 15,1 knots Service: 12,0 knots |
Built |
2007 |
Keel laid |
25/12/2006 |
Launch date |
13/04/2007 |
Date of completion |
30/07/2007 |
Builder |
Jiangsu Yangzijiang Shipbuilding Co., Ltd. Jiangyin China |
Yard number |
YZJ2005-692 |
Hull material |
Steel |
Hull type |
Single hull double bottom, continuous from peak to peak bulkhead |
Bulkheads |
6 |
Continuous decks |
1 |
Main engine |
1x MAN-B&W 7S35MC - 2 stroke 7 cylinder 350 x 1.400 mm combustion engine 5.180 kW at 173,0 rpm Builder: MAN B&W Diesel A/S Frederikshavn - Denmark |
Propellers |
1x Screw propeller controllable pitch - aft at 173,0 rpm |
Boilers |
1x Auxiliary boiler, composite - 9,0 bar Heating surface: 26,8 m² Heating surface: 197,5 m² Manufacturer: KangRim Industries Co., Ltd. (3rd Factory) |
Generators |
1x MAN D 2840 LE 301 main diesel generatorset 500 kVA - 400 kW - 602 hp 2x MAN D 2840 LE 301 main diesel generatorsets each 500 kVA - 400 kW - 700 hp |
Emergency generator |
1x MAN D 0824 LE 201 Diesel generatorset 125 kVA - 100 kW - 149 hp |
Compressed air receivers |
1x Receiver 50 litres - 33,0 bar 2x Receivers each 1.000 litres - 30,0 bar 1x Receiver 160 litres - 30,0 bar 1x Receiver 250 litres - 11,0 bar 1x Receiver 80 litres - 8,3 bar |
Bow thruster |
1x Controllable pitch propeller 500 kW |
Number of cargo holds |
3 |
Total capacity of holds |
16.380,10 m³ |
Number of hatches |
3 |
Tank capacities |
Fuel: 981,3 m³ Ballast: 4.394,2 m³ |
Anchor equipment |
3x Anchors weight each 4.320 kg Chain Length: 550,00 m |
Cargo gear |
2x Deck cranes - SWL 35,0 t each |
Registered owner |
Fulmar Shipping & Trading Co., Ltd. |
Latest data adjustment |
05 August 2020 |
