Flinterduin 01

Westerschelde 01 October 2015



Name

FLINTERDUIN

Type

Multi Purpose general cargo

IMO-number

9213882

Call sign

PEBT

Flag

The Netherlands

Port of registry

Groningen

GT

4.503 t

DWT

6.259 t

NT

2.462 t

Number of 20ft containers

On hatches: 163

In hold: 227

Total: 390

Reefer capacity

25

Length

111,75 m overall

105,34 m Between perpendiculars

Breadth

14,95 m

Draught

Max: 6,38 m

Air draft

40,85 m ballast

Freeboard

1.742 mm

Depth

8,25 m

Speed

Service: 14,3 knots

Built

2000

Launch date

27/05/2000

Date of completion

29/06/2000

Builder

Ferus Smit Leer GmbH

Leer

Germany

Yard number

324

Hull material

Steel

Watertight compartments

6

Movable bulkheads

2x Moveable each 2 parts

Continuous decks

1

Main engine

1x Wärtsilä 8R32E - 4 stroke single acting 8 cylinder 320 x 350 mm 3.280 kW/ 4.159 hp at 720 rpm

Builder: Wärtsilä NSD Finland Oy, Vaasa - Finland

Propellers

1x Controllable pitch propeller - aft at 195 rpm

Boilers

1x CHO ECO Processtechnik 17,00 m² - 10,0 bar

1x CHR ECO Prozesstechnik 40,00 m² / 10,0 bar

Electric installations

Power voltage: 400 V

Lighting voltage: 230 V

Frequency: 50 Hz

Shaft generator

1x 344 kW / 380 V 50 Hz

Generators

2x Cummins diesel engine each 163 kW connected to generators each 160 kW / 380 Volt 50 Hz

Emergency generator

1x Diesel generatorset 106 kVA - 85 kW - 145 hp

Bow thruster

1x Controllable pitch thruster 350 kW / 476 hp, forward

Number of holds

2

Hold 1: 27,30 x 12,65 x 9,44 m

Hold 2: 53,70 x 12,65 x 9,44 m

Cargo hold capacity

Grain: 9.052 m³

Bale: 8.620 m³

Hold ventilation

6x Air changes/hour

Number of hatches

2

Hatch 1: 27,30 x 12,65 m

Hatch 2: 53,70 x 12,65 m

Hatch type

Pontoon

Max permitted loads

Tanktop: 15,0 t/m²

Hatchcover: 1,75 t/m²

Tank capacities

IFO: 438,75 m³

MGO: 41 m³

fresh water: 44,4 m³

Ballast water: 2.529,4 m³

Cargo gear

Gearless

Crew

9

Manager

Flinter Groningen B.V.

Groningen

The Netherlands

Owner

Flinterduin II B.V.

Groningen

The Netherlands

Previous owners

06/2000 - 05/2009 C.V. Scheepvaartonderneming Flinterduin, Groningen - The Netherlands

05/2009 - 09/2016 Flinterduin B.V., Groningen - The Netherlands

Renamed

04/2017 Longduin

The Netherlands, Groningen - Call sign: PEBT

Manager: Longship B.V., Groningen - The Netherlands

Owner: Longduin Shipping B.V., Groningen, The Netherlands

Latest data adjustment

08 August 2020
