Echion 01

Westerschelde 20 June 2018



Name

ECHION

Type

Multi-purpose dry cargo ship - Equipped for carriage of containers - Boxshaped

IMO-number

9496587

Call sign

V2HC7

Flag

Antigua & Barbuda

Port of registry

St. John’s

Previous flags

2010 - 2018 Liberia, Monrovia - Call sign: A8UY2

GT

2.452 t

DWT

Summer: 3.685,49 t

Winter: 3.544 t

NT

1.369 t

Number of 20ft containers

176

Length

87,84 m overall

81,24 m between perpendiculars

Breadth

12,90 m extreme

Draught

Summer: 5,51 m

Winter: 5,39 m

Keel to top antenna

21,80 m forward / 25,00 m aft

11,50 m forward / 19,30 m aft lowered mast

Air draft

Max: 21,50 m

Depth

7,10 m moulded

Speed

Max: 11,0 knots

Built

2010

Keel laid

29/06/1998

Launch date

26/02/2010

Date of completion

27/04/2010

Builder

Slovenske Lodenice Komarno A.S.

Komarno Slovakia

Slovakia

Yard number

2982

Hull material

shipbuilding steel

Hull type

Partly double bottom (e.g. interrupted in way of machinery space)

Main engine

1x MaK 8M20C - 8 cylinder combustion engine 1.540 kW at 1.000 rpm

Propellers

1x Controllable pitch propeller

Boilers

1x Auxiliary boiler, oil/gas fired (oil fired water heater)

Generators

2x Sisu 645 DSBIG main diesel generatorsets

Emergency generator

1x Sisu 320 DSG diesel generatorset

Number of holds

1x Boxshaped

Cargo hold capacity

162.000 ft³

Hold ventilation

6x times/h

Number of hatches

1

56,55 x 11,20 m

Hatch type

Kvaerner Multifold Crocodile

Max permitted loads

Hatch cover: 1,6 t/m²

Tanktop: 15,0 t/m²

Tank capacities

Ballast: 1.340,36 m³

IFO: 191,5 t

MDO: 180,3 m³

Anchor equipment

Length: 440,00 m

Diameter: 32 mm

Manager

Wessels Reederei GmbH & Co., KG

Industriestr. 12-14

49733 Haren Ems

Germany

Owner

Echion Schiffahrts GmbH & Co., KG

Industriestr. 12-14

49733 Haren Ems

Germany

Renamed

2020 Wilson Dundalk

Antigua & Barbuda, St. John’s - Call sign: V2HC7

Owner: MS "WES Echion" Schiffahrts GmbH & Co. KG, Haren - Germany

Manager: Wessels Reederei GmbH & Co. KG, Haren - Germany

Latest data adjustment

27 October 2020
