Spijkenisse, The Netherlands 23 September 2020 |
 |
 |
|
| Spijkenisse 23 September 2020 | Westerschelde 30/03/20 | |
|
Name |
STAR JUVENTAS |
|
Type |
Open hatch general cargo carrier / Containers arranged in holds and on deck |
|
Main products |
Baled pulp, ore, grain, cement, paper, packaged lumber and other solid bulk cargoes |
|
IMO-number |
9254642 |
|
Call sign |
LAZU5 |
|
Flag |
Norway |
|
Port of registry |
Bergen |
|
GT |
32.679 t |
|
DWT |
Summer: 44.837 t |
|
NT |
13.085 t |
|
Number of 20ft containers |
On hatch covers: 720 In holds: 1.350 Total: 2.070 |
|
Length |
198,00 m overall 187,03 m between perpendiculars |
|
Breadth |
32,00 m |
|
Draught |
Summer: 12,00 m |
|
Freeboard |
3.616 mm |
|
Depth |
19,00 m |
|
Speed |
16,0 knots |
|
Built |
2004 |
|
Builder |
Mitsui Engineering & Shipbuilding Co. Ltd., Tamano Works Okayama Japan |
|
Yard number |
1531 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Continuous decks |
1 |
|
Main engine |
1x Mitsui B&W 6S60MC -2 stoke single acting 6 cylinder 600 x 2.292 mm combustion engine MCR 10.520 kW / 14.293 hp at 96,0 rpm NSR 9.470 kW at 92,7 rpm Manufacturer: Mitsui & Co., Ltd., Tamano - Japan |
|
Propellers |
1x Screw propeller solid |
|
Boilers |
1x Auxiliary Boiler OEV-120-14 - 6,0 kg/cm² Steam production: 1.200 kg/h 1x Exhaust gas economizer DC-061510-1B - 6,0 kg/cm² Steam production: 1.100 kg/h |
|
Generators |
2x Rolls Royce KRG-8 - 4 stroke 8 cylinder diesel engines each output 1.370 kW at 720 rpm connected with generator each output 1.300 kW / 1.625 kVA 1x Rolls Royce KRG-5 - 4 stroke 5 cylinder diesel output 760 kW connected with generator output 720 kW / 900 kVA |
|
Emergency generator |
1x Diesel generatorset 100 kVA - 80 kW - 143 hp Manufacturer: Mitsui Zosen Machinery & Service Inc. |
|
Compressed air receivers |
2x Sperre HV2/200 - 136 m³/h capacity at 30,0 bar 1x Sperre HV2/300A - 437 m³/h capacity at 8,0 bar |
|
Thruster |
1x 1.900 hp, forward 1x 990 hp, aft |
|
Number of holds |
11x Box-shaped cargo holds - Dehumidification system for all cargo holds |
|
Cargo hold capacity |
Hold 1: 4.048,8 m³ / 142.983 ft³ Hold 2: 5.510,5 m³ / 194.603 ft³ Hold 3: 6.206,4 m³ / 219.179 ft³ Hold 4: 6.206,4 m³ / 219.179 ft³ Hold 5: 6.206,4 m³ / 219.179 ft³ Hold 6: 6.206,4 m³ / 219.179 ft³ Hold 7: 6.206,4 m³ / 219.179 ft³ Hold 8: 6.206,4 m³ / 219.179 ft³ Hold 9: 6.206,4 m³ / 219.179 ft³ Hold 10: 5.722,2 m³ / 202.078 ft1 Hold 11: 2.764,7 m³ / 97.635 ft³ Total: 61.490,90 m³ |
|
Tank capacities |
Fuel: 2.395,1 m³ |
|
Cargo gear |
2x Gantry cranes - SWL 69 t each |
|
Accommodation |
Aft for a total of 29 persons |
|
Manager |
Grieg Star AS C Sundtsgate 17/19 5004 Bergen Norway |
|
Operator |
G2 Ocean AS Grieg-Gaarden, C. Sundtsgate 17 NO-5809 Bergen Norway |
|
Registered owner |
Grieg International II AS Bryggegata 6 0250 Oslo Norway |
|
Latest data adjustment |
26 February 2021 |
