Westerschelde 30 March 2020 |
|
Name |
TRANS SPRING |
|
Type |
Bulk carrier |
|
IMO-number |
9615482 |
|
Call sign |
VRJF6 |
|
Flag |
Hong Hong - China |
|
Port of registry |
Hong Kong |
|
GT |
33.044 t |
|
DWT |
Summer: 56.853 t |
|
NT |
19.231 t |
|
Length |
189,99 m overall 185,00 m between perpendiculars |
|
Breadth |
32,26 m moulded |
|
Draught |
11,30 m |
|
Forecastle |
13,01 m |
|
Deckhouse |
22,66 m |
|
Freeboard |
5.224 mm |
|
Depth |
18,00 m moulded |
|
Speed |
14,2 knots |
|
Built |
2011 |
|
Date of completion |
07/11/2011 |
|
Builder |
Xiamen Shipbuilding Industry Co.,Ltd. China |
|
Yard number |
XS1407G |
|
Hull material |
Steel |
|
Bulkheads |
6 |
|
Continuous decks |
1x Upper deck |
|
Main engine |
1x Hyundai/MAN-B&W 6S50MC-C7 - 6 cylinder combustion engine 9.480 kW at 127,0 rpm Build: 21/06/2011 Builder: Hyundai Heavy Industries Co.,Ltd. - South Korea |
|
Propellers |
1 |
|
Boilers |
Builder: Aalborg Industries Ltd. |
|
Generators |
3x Main diesel generatorsets each 600 kW - 450 Volt |
|
Number of cargo holds |
5 |
|
Cargo hold capacity |
Grain: Hold 1: 13.009,86 m³ Hold 2: 15.333,25 m³ Hold 3: 14.553,08 m³ Hold 4: 15.333,27 m³ Hold 5: 13.404,64 m³ Total: 71.634,1 m³ |
|
Number of hatches |
5 4x 21,32 x 18,26 m 1x 18,86 x 18,26 m |
|
Tank capacities |
Ballast: 15.763 m³ |
|
Lifting equipment |
1x Engine room overhead Crane - SWL 3,0 t 1x Provision crane - SWL 4,0 t |
|
Cargo gear |
4x Deck cranes - SWL 30,0 t each |
|
Crew size |
27 |
|
Operator |
Amoysailing Maritime Co., Ltd. 26H, 99 LuJiang Avenue Xiamen 361001 China |
|
Registered owner |
Spring Maritime Limited |
|
Latest data adjustment |
09 April 2021 |
