Westerschelde 04 August 2014 |
 |
| Terneuzen 04/09/14 |
|
Name |
TRANSANDROMEDA |
|
Previous names |
10/1999 - 05/2009 Andromeda |
|
Type |
Multi-purpose dry cargo ship - Equipped for carriage of containers, Strengthened for heavy cargo |
|
IMO-number |
9187916 |
|
Call sign |
ZDNJ3 |
|
Flag |
Gibraltar |
|
Port of registry |
Gibraltar |
|
Previous flags |
10/1999- 2013 The Netherlands, Rotterdam - Call sign: PCFO |
|
GT |
4.893 t |
|
DWT |
6.725 t |
|
NT |
2.608 t |
|
Number of 20ft containers |
In hold: 174 Hatches: 242 Total: 416 |
|
Reefer plugs |
25 |
|
Length |
118,55 m overall 111,35 m between perpendiculars 112,15 m registered |
|
Breadth |
15,20 m moulded |
|
Draught |
Summer: 6,32 m |
|
Air draft |
35,00 m |
|
Depth |
8,45 m to upper deck |
|
Speed |
15,0 knots |
|
Built |
1999 |
|
Keel laid |
18/12/1998 |
|
Launch date |
11/09/1999 |
|
Date of completion |
19/11/1999 |
|
Builder |
Bodewes Shipyards B.V. Werfkade 22 9601 LG Hoogezand The Netherlands |
|
Yard number |
587 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
8 |
|
Movable bulkhead |
2x Enabling to make part tweendeck of 18,90 x 12,65 m Height 4,50 m in lowehold, also to be used as 4 separation bulkheads of 4,70 m |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 8M32 - 4 stroke single acting 8 cylinder 320 x 480 mm combustion engine 3.840 kW / 5.222 bhp at 600 rpm Year of manufacture: 1999 Manufacturer: MaK Deutschland Branch of Caterpillar Motoren GmbH & Co. KG, Kiel Service Station Kiel Am Holzhafen 7 28217 Bremen Federal Republic of Germany |
|
Propellers |
1x Controllable pitch propeller - aft at 158 rpm |
|
Electric installations |
2x Plants each 400 V - 330 kVA 1x Plant 400 V - 435 kVA 1x Plant 400 V - 72 kVA |
|
Shaft generator |
1x Stamford 435 kVA |
|
Generators |
2x Scania marine diesel engines each 275 kW at 1.500 rpm connected with Stamford generator each 330 kVA / 380 Volt 50 Hz |
|
Emergency generator |
1x Valmet marine diesel engine 80 kW at 1.500 rpm connected with Stamford generator 71 kVA / 380 V 50 Hz |
|
Compressed air receivers |
2x Receivers each 250 litres - 30,0 bar |
|
Bow thruster |
1x Bow thruster 300 kW, forward |
|
Deck machinery |
4x Electric-hydraulic operated mooring winches |
|
Number of hold |
2 Hold 1: 39,00 x 12,65 x 9,45 m Hold 2: 42,75 x 12,65 x 9,45 m |
|
Hold capacity |
Hold 1: 4.308 m³ / 152.120 ft³ Hold 2: 5.112 m³ / 180.513 ft³ Total: 9.420 m³ / 332.633 ft³ |
|
Hold ventilation |
Hold 1:30 Air changes Hold 2: 6 Air changes |
|
Number of hatches |
2 Hatch 1: 39,00 x 12,65 m Hatch 2: 42,75 x 12,65 m |
|
Max permitted loads |
Tanktop: 15 t/m² Tweendeck: 2,0 t/m² |
|
Tank capacities |
Ballast: 3.187 m³ Fuel oil: 513 m³ Gas oil: 71 m³ |
|
Anchor equipment |
3x Anchors weight each 3.060 kg Chain Length: 495,00 m |
|
Manager |
Rederi AB Transatlantic Skärhamn Sweden |
|
Previous manager |
10/1999 - 10/2006 B&N Kustvaartbedrijf Moerman B.V. (B&N Nordsjöfrakt A/B), Ridderkerk - The Netherlands 20/2006 - 2013 Kustvaartbedrijf Moerman B.V., Ridderkerk - The Netherlands |
|
Operator |
TransAtlantic |
|
Owner |
TransAtlantic Shipping (4) Ltd. Gothenburg Sweden |
|
Previous names & owners |
10/1999 - 10/2006 Andromeda - C.V Scheepvaartonderneming MS Andromeda, Rotterdam - The Netherlands (Kustvaartbedrijf Moerman B.V.) 10/2006 - 05/2006 Andromeda - Andromeda Shipping Company B.V., Rotterdam - The Netherlands 05/2006 - 2013 Transandromeda - Andromeda Shipping Company B.V., Rotterdam - The Netherlands |
|
Renamed |
05/2016 Kristiina
|
|
Latest data adjustment |
13 September 2024 |
