Westerschelde 20 December 2018 |
 |
 |
|
| Westerschelde 30/12/18 | Westerschelde 30/12/18 |
|
Name |
CEMTEX INNOVATION |
|
Type |
Bulk carrier - Panamax |
|
IMO-number |
9593048 |
|
Call sign |
9V9849 |
|
Flag |
Republic of Singapore |
|
Port of registry |
Singapore City |
|
GT |
45.232 t |
|
DWT |
Summer: 81.326 t |
|
NT |
26.914 t |
|
Length |
229,00 m overall 223,50 m between perpendiculars |
|
Breadth |
32,26 m extreme |
|
Draught |
Summer: 14,47 m |
|
Depth |
20,20 m |
|
Speed |
Max: 17,6 knots Service: 14,5 knots |
|
Built |
2013 |
|
Keel laid |
14/11/2011 |
|
Launch date |
08/02/2012 |
|
Date of completion |
03/06/2013 |
|
Builder |
Guangzhou Longxue Shipbuilding Co., Ltd. Guangzhou China |
|
Yard number |
L0039 |
|
Hull material |
Steel |
|
Continuous decks |
1 |
|
Main engine |
1x MAN-B&W 5S60MC-C MK8 - 2 stroke 5 cylinder 600 x 2.400 mm combustion engine 11.900 kW / 16.179 hp at 105,0 rpm Builder: Hudong Heavy Machinery Co., Ltd. - China |
|
Propellers |
1x Mono-block fixed pitch propeller - aft at 105,0 rpm |
|
Boilers |
1x Auxiliary boiler, composite MISSION OC |
|
Generators |
3x Yanmar 6EY18AL - 4 stroke 6 cylinder 180 x 280 mm diesel engines each 650 kW connected with generators each 620 kW Yanmar Power Technology Co., Ltd. |
|
Emergency generator |
1x Sisu 634 diesel generatorset AGCO Sisu Power, GenPowex |
|
Number of holds |
7 |
|
Cargo hold capacity |
Grain: 97.115 m³ Bale: 90.784 m³ |
|
Tank capacities |
Fuel: 2.950 m³ Diesel oil: 150 m³ Ballast: 38.167,9 m³ |
|
Anchor equipment |
Length: 687,50 m Diameter: 81 mm |
|
Cargo gear |
Gearless |
|
Crew size |
19 |
|
Manager |
U-Ming Marine (Xiamen) International Ship Management Co., Ltd. Rooms 3002 & 3010, Bank Centre, 189, Xiahe Lu, Siming Qu Xiamen China |
|
Registered owner |
U-Ming Marine Transport Corporation 08-01, Cemtex Industrial Building, 5, Little Road Singapore 536983 Republic of Singapore |
|
Latest data adjustment |
24 June 2021 |
