Westerschelde 23 May 2019 |
 |
|
| Vlissingen (NL) 20/04/18 | |
|
Name |
DA JI |
|
Chinese name |
大 吉 |
|
Type |
General dry cargo ship |
|
IMO-number |
9768538 |
|
Call sign |
BOUF |
|
Flag |
China |
|
Port of registry |
Guangzhou |
|
GT |
21.992 t |
|
DWT |
28.612 t |
|
NT |
9.390 t |
|
Number of 20ft containers |
On deck: 1.035 |
|
Length |
179,67 m overall 170,60 m between perpendiculars |
|
Breadth |
28,00 m moulded |
|
Draught |
9,20 m |
|
Deckhouse |
11,25 m |
|
Forecastle |
14,49 m |
|
Bridge |
12,25 m |
|
Poop |
19,80 m |
|
Freeboard |
4.332 mm |
|
Depth |
14,80 m moulded |
|
Speed |
Max: 15,0 knots |
|
Built |
2016 |
|
Keel laid |
22/12/2015 |
|
Launch date |
18/07/2016 |
|
Date of completion |
19/12/2016 |
|
Builder |
Shanghai Shipyard China |
|
Yard number |
1238 |
|
Hull material |
Steel |
|
Bulkheads |
12 |
|
Number of decks |
2 Upper deck - Tween deck |
|
Main engine |
1x Wärtsilä 6RT-Flex50D - 6 cylinder 7.000 kW at 95,0 rpm Build: 01/06/2016 Manufacturer: Hu Dong Heavy Machinery Co., Ltd., Shanghai - China |
|
Boilers |
1x 0,7 MPa /221 m² 1x 0,7 MPA / 30 m² Manufacturer: Zhangjiagang Greens-shazhou Boiler Co., Ltd. |
|
Generators |
3x HFC6 504-14E main diesel generatorsets each 700 ekW / 450 Volt |
|
Number of holds |
3 |
|
Cargo hold capacity |
Grain Hold 1 Cargo hold 8.421,70 m³ Hold 2 Cargo hold 18.275,80 m³ Hold 3 Cargo hold 8.986,80 m³ Total: 35.684,3 m³ |
|
Hatches |
1x 54,00 x 23,20 m 1x 30,00 x 23,20 m 1x 26,25 x 23,20 m |
|
Tank capacities |
Ballast: 10.115 m³ |
|
Anchor equipment |
1x Deck crane - SWL 100 t 2x Deck cranes - SWL 350 t each |
|
Lifting equipment |
1x Crane - SWL 2,0 t Engine room overhead crane - SWL 1,3 t |
|
Manager |
COSCO Shipping Specialized |
|
Operator |
COSCO Shipping Specialized Carriers Co., Ltd. |
|
Registered owner |
COSCO Shipping Specialized Carriers Co., Ltd. |
|
Latest data adjustment |
17 August 2021 |
