Westerschelde 31 August 2020 |
|
Name |
LADY ROSEMARY |
|
Type |
Refrigerated cargo ship - Designed for carriage of containers |
|
IMO-number |
9355044 |
|
Call sign |
3EOZ4 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
9.576 t registered |
|
DWT |
Summer: 10.617 t |
|
NT |
5.562 t registered |
|
Light ship |
6.243,93 t |
|
Number of 20ft containers |
176 |
|
Reefer capacity |
100 |
|
Length |
143,00 m overall |
|
Breadth |
22,70 m moulded |
|
Draught |
Summer: 9,02 m |
|
Moulded L x B x D |
133,00 x 22,70 x 13,40 m |
|
Registered L x B x D |
134,17 x 22,70 x 13,40 m |
|
Keel to mast end |
36,20 m |
|
Freeboard |
Summer: 4.413 mm |
|
Depth |
13,40 m moulded |
|
Speed |
Service: 20,0 knots Max: 22,3 knots |
|
Built |
2008 |
|
Keel laid |
22/05/2007 |
|
Launch date |
18/09/2007 |
|
Date of completion |
08/02/2008 |
|
Builder |
Kitanihon Shipbuilding Co., Ltd. Hachinohe Japan |
|
Yard number |
376 |
|
Hull material |
Steel |
|
Main engine |
1x Mitsubishi 8UEC50LSH - 2 stroke single acting 8 cylinder 500 x 1.950 mm combustion engine Mcr 11.560 kW / 15.717 hp at 127,0 rpm Manufacturer: Akasaka Diesels Ltd. - Japan |
|
Propeller shaft |
1x Oil lubrication shaft without monitoring device Diameter: 520 mm |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Auxiliary vertical boiler composite water tube boiler - 0,80 MPa Evaporation: 2,14 t/h Manufacturer: Miura Protec Co., Ltd. - Japan |
|
Generators |
3x Main diesel generatorsets each 1.120 kW |
|
Number of holds |
4 |
|
Cargo capacity |
Refrigerated: 15.660,15 m³ |
|
Number of hatches |
4 |
|
Compartments |
15 |
|
Min temp |
-25°C |
|
Tank capacities |
Fuel oil: 1.691,00 m³ Fresh water: 267,00 m³ |
|
Cargo gear |
2x Cargo deck cranes - SWL 40,0 t each 2x Cargo deck cranes - SWL 8,0 t each |
|
Manager |
Shinsei Kaiun Co., Ltd. 10th Floor, Muromachi Kyodo Building, 8-17, Nihonbashihon-cho 4-chom, Chuo-ku Tokyo, 103-0023 Japan |
|
Registered owner |
Rising Sun Line, S.A. Republic of Panama |
|
Latest data adjustment |
21 November 2021 |
