| Westerschelde 15 October 2019 |
 |
|
| Westerschelde 15/10/19 | |
|
Name |
KAREN C |
|
Type |
General cargo ship - Heavycargo- Equipped for carriage of containers - Box sid |
|
IMO-number |
9523952 |
|
Call sign |
2DCC7 |
|
Flag |
United Kingdom |
|
Port of registry |
Cowes |
|
GT |
4.151 t |
|
DWT |
Summer: 6.800 t |
|
DWCC |
Summer: 6.300 t Winter: 6.200 t |
|
NT |
2.323 t |
|
Light ship |
2.053,26 t |
|
Number of 20ft containers |
70 |
|
Length |
106,07 m overall 100,92 m between perpendiculars |
|
Breadth |
15,50 m |
|
Draught |
Summer: 6,63 m Winter: 6,49 m |
|
Air draft |
28,60 m ballast |
|
Freeboard |
1.522 mm |
|
Depth |
8,14 m moulded |
|
Speed |
10,3 knots |
|
Built |
2010 |
|
Keel laid |
10/10/2008 |
|
Date of completion |
01/06/2010 |
|
Builder |
Jiangsu Yangzijiang Shipbuilding Co.,Ltd. Jiangyin China |
|
Yard number |
YZJ2008-894 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Watertight compartments |
2 |
|
Movable bulkheads |
2 Postions hold 1: 4 Postions hold 2: 3 |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 6M25C - 4 stroke 6 cylinder 255 x 400 mm combustion engine 1.980 kW / 2.690 hp at 750 rpm Build: 12/11/2009 Builder: Caterpillar Motoren GmbH & Co.,Ltd., Kiel - Germany |
|
Propellers |
1x Screw propeller controllable pitch - aft at 170 rpm |
|
Boilers |
1x CHO Viessmann Werke 6,90 m² - 6,0 bar |
|
Shaft generator |
1x 390 kVA - 312 kW |
|
Generators |
3x Main diesel generatorsets each 200 kVA - 160 kW - 204 hp |
|
Bow thruster |
1x 250 kW |
|
Number of holds |
2 Hold1: 33,80 x 11,70 x 9,30 m (narrows aft part 6,50 m to 6,00 m Hold 2: 44,10 x 11,70 x 9,30 m (narrows fore part 11,2 m to 6,00 m |
|
Cargo hold capacity |
293.550 ft³ - 8.312,43 m³ |
|
Number of hatches |
2 Hatch 1: 34,50 x 11,70 m Hatch 2: 45,50 x 11,70 m |
|
Hatch type |
Pontoon |
|
Max permitted loads |
Tanktop: 15,0 t/m² Hatches: 2,2 t/m² |
|
Tank capacities |
Fuel oil: 263,0 m³ Fresh water:67,6 m³ Gas oil: 52,3 m³ |
|
Lifting equipment |
1x Gantry crane |
|
Crew size |
10 |
|
Commercial manager |
Vertom Shipping & Trading BV Oever 7 3161 GR Rhoon The Netherlands |
|
ISM manager |
Carisbrooke Shipping Ltd. Bridge House, 38, Medina Road Cowes, PO31 7DA United Kingdom |
|
Registered owner |
Carisbrooke Shipping 6000 Ltd. Care of Vertom Shipping & Trading BV Oever 7 3161 GR Rhoon The Netherlands |
|
Latest data adjustment |
22 December 2022 |
