Name |
KAREN |
|
Previous names |
2008 - 08/2013 EMI Proud |
|
Type |
Multi-purpose dry cargo and container carrier |
|
IMO-number |
9487603 |
|
Call sign |
V2RB6 |
|
Flag |
Antigua & Barbuda |
|
Port of registry |
St. John’s |
|
Previous flags |
2008 - 2023 Malta, Valletta - Call sign: 9HPN9 |
|
GT |
2.997 t |
|
DWT |
4.570 t |
|
NT |
1.621 t |
|
Displacement |
6.403 t |
|
Light ship |
1.514 t |
|
Number of 20ft containers |
138 |
|
Length |
89,99 m 84,51 m between perpendiculars |
|
Breadth |
14,03 m |
|
Draught |
Summer: 6,13 m |
|
Depth |
7,15 m moulded |
|
Speed |
11,5 knots |
|
Build |
2008 |
|
Keel laid |
28/09/2007 |
|
Launch date |
06/06/2008 |
|
Delivery date |
26/11/2008 |
|
Builder |
Onega Arminius Shipyard Petrozavodsk Russia |
|
Yard number |
201 |
|
Hull material |
Steel |
|
Continuous decks |
1 |
|
Number of partial decks |
3 |
|
Main engine |
1x Wärtsilä 6L26B2 - 4 stroke 6 cylinder 260 x 320 mm combustion engine 1.950 kW / 2.651 hp at 900 rpm |
|
Propellers |
1x Controllable pitch propeller |
|
Shaft generator |
1x 292 kW |
|
Generators |
2x Volvo Penta D9A-MG diesel generatorsets each 180 kW |
|
Emergency generator |
1x Volvo Penta D7A-Tdiesel generatorset 85 kW |
|
Bow thruster |
1x 170 kW |
|
Number of holds |
2 Hold 1: 31,00 x 11,50 x 8,50 m Hold 2: 29,00 x 11,50 x 8,50 m |
|
Hold capacity |
Grain: 5.611 m³ / 198.152 ft³ |
|
Humber of hatches |
1 55,00 x 11,50 m |
|
Max permitted loads |
12,0 t/m² |
|
Crew |
9 |
|
ISM & commercial manager |
Hansa Ship Management OU Ahtri tn 12 10151 Tallinn Estonia |
|
Registered owner |
HS Karen OU Care of Hansa Shipping OU Ahtri tn 12 10151 Tallinn Estonia |
|
Latest data adjustment |
11 October 2024 |
