| Westerschelde 27 April 2017 |
 |
 |
|
| Westerschelde 27/04/17 | Westerschelde22/08/15 | |
|
Name |
HONG DAI |
|
Type |
Bulk carrier - Strengthened for heavy cargoes Panamax |
|
IMO-number |
9563603 |
|
Call sign |
3FMU7 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
40.896 t |
|
DWT |
76.556,62 t |
|
NT |
25.825 t |
|
Length |
225,00 m overall 217,00 m between perpendiculars |
|
Breadth |
32,26 m moulded |
|
Draught |
Summer: 14,20 m |
|
Forecastle |
14,80 m |
|
Deckhouse |
22,80 m |
|
Freeboard |
5.420 mm |
|
Depth |
19,60 m moulded |
|
Speed |
Max: 14,5 knots |
|
Built |
2010 |
|
Keel laid |
05/09/2009 |
|
Date of completion |
30/04/2010 |
|
Builder |
CSSC Guangzhou Huangpu Shipbuilding Co., Ltd. China |
|
Yard number |
HPS3002 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Bulkheads |
9 |
|
Continuous decks |
1x Upper deck |
|
Main engine |
1x Hudong/MAN-B&W 5S60MC - 2 stroke single acting 5 cylinder 600 x 2.292 mm combustion engine Mcr 8.833 kW at 105,0 rpm Build: 08/07/2009 Builder: Hudong Heavy Machinery Co., Ltd., Shanghai - China |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Auxiliary composite boiler - 0,7 MPa Heating surface: 24 / 255 m² Builder: Saacke (Qingdao) Marine Boiler Co.,Ltd. |
|
Generators |
3x Main diesel generatorsets each 560 kVA / 450 Volt |
|
Number of holds |
7 |
|
Cargo hold capacity |
Grain: Hold 1: 10.632,70 m³ Hold 2: 13.607,41 m³ Hold 3: 13.264,39 m³ Hold 4: 13.196.74 m³ Hold 5: 13.272,16 m³ Hold 6: 13.260,58 m³ Hold 7: 12.865,90 m³ Total: 90.099,88 m³ |
|
Number of hatches |
7 6x 15,48 x 14,40 m 1x 14,62 x 13,20 m |
|
Tank capacities |
Ballast: 36.983 m³ |
|
Lifting equipment |
1x crane - SWL 4,5 t |
|
Manager |
COSCO Shipping Bulk Co., Ltd. Guangzhou China |
|
Registered owner |
Fruition Carriers Corporation S.A. - Republic of Panama Care of COSCO (HK) Shipping Co Ltd. - Hong Kong |
|
Latest data adjustment |
12 April 2023 |
