Name |
OKIANA |
|
Previous names |
2004 - 2009 Star Okiana |
|
Type |
Gantry craned open-hatch bulk carrier - Forest product carrier |
|
IMO-number |
9253868 |
|
Call sign |
2HBU3 |
|
Flag |
Isle of Man - United Kingdom |
|
Port of registry |
Douglas |
|
Previous flags |
2004 - 2022 Republic of Singapore, Singapore City - Call sign: 9VAR8 |
|
GT |
38.910 |
|
DWT |
54.683 t |
|
NT |
15.962 t |
|
Number of 20ft containers |
2.268 |
|
Length |
212,50 m overall 202,50 m between perpendiculars |
|
Breadth |
32,30 m extreme |
|
Draught |
Summer: 12,30 m |
|
Depth |
19,00 m |
|
Speed |
16,0 knots |
|
Built |
2004 |
|
Keel laid |
06/08/2003 |
|
Launch date |
08/12/2003 |
|
Date of completion |
01/04/2004 |
|
Builder |
Oshima Shipbuilding Co., Ltd. Nagasaki-Oshima Japan |
|
Yard number |
10332 |
|
Hull material |
Steel |
|
Bulkheads |
Transverse: 14 |
|
Main engine |
1x MAN-B&W 6S60MC - 6 cylinder 600 x 2.292 mm combustion engine 11.677 kW / 15.660 bhp Builder: Kawasaki Heavy Industries Ltd. - Japan |
|
Propellers |
1x Fixed pitch mono-block propeller Builder: Nakashima Propeller Co., Ltd. |
|
Boilers |
1x Auxiliary boiler, composite GCS-22ST Builder: Aalborg Industries A/S |
|
Generators |
2x MAN-B&W 6L28/32H main diesel generatorsets each 1.263 kW 1x MAN-B&W 5L28/32H main diesel generatorsets 1.064 kW |
|
Emergency generator |
1x Deutz BF 6L 913 diesel generatorset |
|
Bow thruster |
1x Rolls-Royce KaMeWa Ulstein TT 2200 controllable pitch thruster 1.500 kW, forward 1x Rolls-Royce KaMeWa Ulstein TT 1650 III controllable pitch thruster 750 kW, aft |
|
Number of cargo holds |
12 |
|
Cargo hold capacity |
Hold 1: 4.852 m³ / 171.347 ft³ Hold 2: 6.332 m³ / 223.613 ft³ Hold 3: 6.498 m³ / 229.228 ft³ Hold 4: 6.498 m³ / 229.228 ft³ Hold 5: 6.498 m³ / 229.228 ft³ Hold 6: 6.498 m³ / 229.228 ft³ Hold 7: 6.498 m³ / 229.228 ft³ Hold 8: 6.498 m³ / 229.228 ft³ Hold 9: 6.498 m³ / 229.228 ft³ Hold 10: 6.498 m³ / 229.228 ft³ Hold 11: 6.014 m³ / 212.383 ft³ Hold 12: 2.703 m³ / 95?456 ft³ Total: 71.885 m³ / 2.536.623 ft³ |
|
Tank capacities |
Ballast: 17.627,1 m³ Bunker capacity: 2.852 t |
|
Anchor equipment |
Length: 660,00 m Diameter: 78 mm |
|
Cargo gear |
Travelling gantry cranes full weather protection - SWL 68 t each |
|
Manager |
Zeaborn Ship Management 1 Maritime Square, #11-03 Harbourfront Centre Singapore City 099253 republic of Singapore |
|
Operator |
Saga Welco |
|
Registered owner |
Masterbulk A/S Republic Singapore |
|
Previous names & owners |
2004 - 2009 Star Okiana - Masterbulk Private Limited (Westfal-Larsen Management A/S, Bergen) |
|
Remarks |
2014 Lengthened |
|
Latest data adjustment |
25 June 2023 |
