| Vlissingen 01 June 2015 |
|
Name |
WERRA |
|
Previous names |
2001 - 09/2013 Korsika |
|
Type |
General cargo ship - Equipped for carriage of containers |
|
IMO-number |
9192636 |
|
Call sign |
V2GL2 |
|
Flag |
Antigua and Barbuda |
|
Port of registry |
St. John’s |
|
GT |
2.997 t |
|
DWT |
4.443 t |
|
NT |
1.741 t |
|
Number of 20ft containers |
In hold: 168 On deck: 129 Total: 297 |
|
Container capacity 14t |
185 |
|
Reefer capacity |
30 |
|
Length |
99,90 m overall 95,80 m registered |
|
Breadth |
12,80 m registered |
|
Draught |
5,67 m |
|
Air draft |
23,00 m |
|
Freeboard |
1.898 mm |
|
Depth |
7,55 m |
|
Speed |
Max: 13,3 knots Service: 12,5 knots |
|
Built |
2001 |
|
Keel laid |
23/04/1998 |
|
Launch date |
29/11/2000 |
|
Date of completion |
10/05/2001 |
|
Builder |
Slovenske Lodenice a.s. Rolnickej Skoly 1519 945 25 Komarno Slovak Republic |
|
Yard number |
3022 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Partly double bottom (e.g. interrupted in way of machinery space) |
|
Watertight bulkheads |
4 |
|
Continuous decks |
2 |
|
Main engine |
1x Deutz TBD645L6 - 4 stroke single acting 6 cylinder 330 x 450 mm combustion engine Mcr 2.550 kW / 3.467 hp at 600 rpm Year of manufacture: 1999 Manufacturer: Deutz MWM Motoren-Werke Mannheim AG Mannheim Federal Republic of Germany |
|
Propellers |
1x Controllable pitch propeller - aft at 304 rpm |
|
Boilers |
1x Water heater, oil fired - 4,0 bar |
|
Electric installations |
2x Plant 380/220 V each 210 kVA 1x Plant 380 V - 844 kVA 1x Plant 380 V - 49 kVA |
|
Shaft generator |
1x 640 kW / 844 kVA |
|
Generators |
2x MWM TBD234V8 - 4 stroke 8 cylinder 128 x 140 mm diesel engines each Mcr 175 kW connected with generators 168 kW / 210 kVA - 380/200 Volt |
|
Emergency generator |
1x Diesel generatorset 49 kVA |
|
Compressed air receivers |
1x Receiver 355 litres - 30,0 bar 1x Receiver 250 litres - 30,0 bar |
|
Bow thruster |
1x Transverse fixed pitch thruster JASTRAM - 220 kW / 299 bhp, forward |
|
Number of holds |
1 70,85 x 10,20 x 8,17 m |
|
Cargo hold capacity |
Bales & Grain: 5.842 m³ / 206.310 ft³ |
|
Number of hatches |
2 Hatch 1: 37,95 x 10,20 m Hatch 2: 31,25 x 10,20 m |
|
Hatch type |
Hydraulic folding type |
|
Tank capacities |
Ballast water: 1.705 m³ Fuel: 207 m³ |
|
Anchor equipment |
3x Anchors weight each 2.100 kg Chain length: 440.00 m |
|
Crew size |
8 |
|
Manager |
Erwin Strahlmann GmbH & Co KG Schleusenstrasse 10 25541 Brunsbuettel Germany |
|
Owner |
Roland Ship Administration c/o Reederei Erwin Strahlmann e.K. Brunsbuttel Germany |
|
Previous names & owners |
2001 - 09/2013 Werra - Korsikahill Shipping Ltd. - Antigua and Barbuda |
|
Renamed |
2021 Werratal Antigua and Barbuda, St. John’s - Call sign: V2GL2 Owner: Whitefalls Maritime Ltd. Manager: Glory Denizcilik Ve Gemi Isletmeciligi Ltd Sti, Istanbul - Turkey |
|
Latest data adjustment |
11 October 2023 |
