| Vlissingen 16 January 2018 |
|
Name |
KANG SHENG KOU |
|
Chinese name |
康盛口 |
|
Type |
Semi-submersible heavy lift vessel |
|
IMO-number |
9223289 |
|
Call sign |
BOKF |
|
Flag |
China |
|
Port of registry |
Guangzhou |
|
GT |
15.840 t |
|
DWT |
20.131 t |
|
NT |
4.752 t |
|
Length |
156,00 m overall 145,00 m between perpendiculars |
|
Breadth |
36,00 m moulded |
|
Draught |
7,40 m |
|
Forecastle |
30,00 m |
|
Deckhouse |
19,20 m |
|
Freeboard |
2.622 mm |
|
Depth |
10,00 m moulded |
|
Speed |
14,0 knots |
|
Built |
2003 |
|
Keel laid |
01/12/1999 |
|
Launch date |
22/06/2001 |
|
Date of completion |
15/08/2003 |
|
Builder |
CSSC Offshore & Marine Engineering (Group) Company Limited Guangzhou China |
|
Yard number |
9130013 |
|
Hull material |
Steel |
|
Bulkheads |
5x Transverse bulkheads Longitudinal bulkheads 1 at centreline, 2 at 8,80 meters and 2 at 16,1 meters from centreline |
|
Continuous decks |
1x Main deck |
|
Main engine |
Diesel-Electric 3x Wärtsilä 9R32 - 4 stroke 9 cylinder 320 c 350 mm combustion engines total 10.125 kW / 13.767 hp at 750 rpm |
|
Propulsion |
2x Azimuth |
|
Generators |
3x Main diesel generatorsets each 900 kW / 450 Volt |
|
Bow thruster |
2x 800 kW each |
|
Deck submersion |
9,00 m |
|
Cargo deck |
125,00 x 36,00 m |
|
Max permitted load on main deck |
18,0 t/m² |
|
Tank capacities |
Ballast: 40.073 m³ |
|
Accommodation |
For 38 persons |
|
ISM & commercial manager |
COSCO Shipping Specialized Carriers Co., Ltd. Guangzhou Ocean Plaza 20, Huacheng Dadao, Tianhe Qu Guangzhou, Guangdong, 510623 China |
|
Registered owner |
COSCO Shipping Specialized Carriers Co., Ltd. Guangzhou Ocean Plaza 20, Huacheng Dadao, Tianhe Qu Guangzhou, Guangdong, 510623 China |
|
Latest data adjustment |
12 August 2024 |
