Westerschelde 07 June 2017 |
Name |
DELTADIEP |
Type |
Multi-purpose cargo ship - Equipped for carriage of containers and heavy cargoes |
IMO-number |
9519042 |
Call sign |
5BQA3 |
Flag |
Cyprus |
Port of registry |
Limassol |
GT |
4.358 t |
DWT |
Summer: 5.700 t 5.350 at 5,30 m |
NT |
2.525 t |
Number of 20ft containers |
In hold: 156 On deck: 105 Total: 261 |
Length |
105,22 m overall 99,98 m between perpendiculars |
Breadth |
15,20 m moulded Max: 15,63 m |
Draught |
Summer: 5,97 m |
Air draft |
27,50 m ballast masts collapsed |
Depth |
7,90 m moulded |
Speed |
Max: 12,0 knots Service: 10,0 knots |
Build |
2012 |
Keel laid |
16/10/2006 |
Launch date |
03/07/2012 |
Date of completion |
14/09/2012 |
Builder |
Rong Cheng Shipbuilding Industry Co., Ltd. Rongcheng China |
Yard number |
RC 26 |
Hull material |
Steel |
Hull type |
Double side skin |
Movable bulkheads |
2x Bulkheads (2 panels for each b/h = 4 total erection possible in 3 different positions In hold and 2 positions in hold 1) |
Main engine |
1x Yanmar 6EY26 - 4 stroke 6 cylinder diesel engine engine 1.920 kW at 750 rpm |
Propellers |
1x Controllable pitch propeller |
Shaft generator |
1x 350 kW / 400 volt 50 Hz |
Generators |
3x Deutz MWM TBD 234V8 main diesel generatorsets each 249 kW at 1.500 rpm connected with generators each 230 kW / 400 Volt 50 Hz |
Bow thruster |
1x Kawasaki - 300 kW |
Number of holds |
2 Hold 1: 25,50 x 12,65 x 9,20 m Hold 2: 45,75 x 12,65 x 9,20 m |
Cargo hold capacity |
Grain: 8.265,61 m³ Bale: 8.069 m³ |
Hold ventilation |
6x Air changes per hour |
Number of hatches |
2 |
Hatch cover type |
4x Pontoon on hatch 1 + 7 pontoons on 2 |
Deck aria |
Main deck: 945 m² Weather deck: 900 m² Total: 1.845 m² |
Max permitted loads |
Tanktop: 15,0 t/m² Weatherdeck: 2,2 t/m² Tweendeck: 2,4 t/m² |
Tank capacities |
HFO: 261,3 m³ MDO: 76,15 m³ Fresh water: 58,0 m³ |
Cargo gear |
2x Deck cranes - SWL 45,0 t each, Portside Combinable to 90,0 t |
Commercial manager |
MTL Maritime Transport & Logistik GmbH & Co., KG August-Hirsch-Strasse 10 47119 Duisburg Germany |
ISM manager |
Intership Navigation Company Ltd. Limassol Cyprus |
Owner |
Orient Emerald Shipping Company Ltd. Limassol Cyprus |
Renamed |
02/2018 Kroksoe Cyprus, Limassol - Call sign: 5BQA3 Manager: MTL Maritime Transport & Logistik GmbH & Co., KG Owner: Orient Emerald Shipping Company Ltd. 02/2021 Jasperland Portugal, Madeira - Call sign: CQES3 Reg. Owner: MS "JASPERLAND" GmbH & Co. KG Manager: Tom Worden Gmbh & Co., KG - Oldendorf, Germany |
Latest data adjustment |
24 October 2024 |
