Maras - IMO 9380726

Name

MARAS

Previous names

10/2007 - 02/2015 Karina G

Type

General cargo - Multi-purpose / Bulk carrier

Strengthened for heavy cargo

Basic functions

Transport of bulk - steel coils - containers - forest products

IMO-number

9380726

Call sign

V2CH2

Flag

Antigua & Barbuda

Port of registry

St. John’s

GT

2.545 t

DWT

3.875 t

NT

1.460 t

Number of 20ft containers

In hold: 108

On deck: 80

Total: 188

Length

88,60 m overall

84,99 m between perpendiculars

Breadth

12,52 m moulded

Draught

Summer: 5,47 m

Ballast: 3,20 m

Depth

7,00 m

Speed

Max: 12,5 knots

Service: 10,3 knots

Build

2007

Keel laid

04/01/2006

Launch date

18/04/2007

Delivery date

01/10/2007

Builder casc

Kiev Shipbuilding & Repair Yard

Kiev

Ukraine

Builder

Damen Shipyard BV

Bergum

The Netherlands

Yard number: 9388

Hull material

Steel

Hull type

Single hull

Bulkheads

2

Main engine

1x MaK 8M20 - 4strokee 8 cylinder combustion engine output 1.520 kW / 2.067 hp at 1.000 rpm

Propellers

1x Controllable pitch propeller

Diameter 2.600 mm

Shaft generator

1x 330 kVA - 50Hz

Generators

1x Sisu 634 DSBIG diesel generatorset 175 kVA - 50 Hz

Emergency generator

1x Sisu diesel generatorset 77 kVA - 50Hz

Bow thruster

1x Fixed pitch propeller - 220 kW, electrically driven

Auxiliary equipment

• 2x starting air compressors

• 1x HFO separator

• 1x LO separator

• 1x GO separator

• 1x Booster-unit

• 2x Fuel oil trim pimps

• 1x Bilge water separator, acc. To Marpol regulations

• 2x General service pumps each 150 m³/h at 2,30 bar

• 1x Fire fighting pump

• 1x Freshwater pressure set

• 1x CO2 fire fighting system for engine room and cargo hold

• 1x steering gear unit

Deck lay-out & equipment

• 1x Elec. driven bow anchor winch with two warping heads

• 1x Elec. driven capstan aft

• Rudder, fishtail type

• Container fittings in tanktop and on hatch covers

• Lashing eyes in hold and on outside of coaming

• 2x Moveable grain bulkheads with 8 stowage positions

• Electrically driven hold ventilation for 6 air changes per hour

Number of holds

1

Cargo hold capacity

Bale: 5.250 m³ - 185.400 ft³

Hatches

Weatherdeck hatches dim. approx. 62,70 x 10,10 m

Steel pontoon hatches with gantry crane

Max permitted loads

Tanktop: 15,0 t/m²

Tank capacities

HFO: 156 m³

Gas oil: 55 m³

Lub. oil clean: 8,6 m³

Dirty oil: 4 m³

Sludge: 4 m³

Sewage: 12 m³

Portable water: 55 m³

Ballast water: 1.372,8 m³

Anchor equipment

Length: 440,00 m

Diameter: 32 mm

Accommodation

For captain and crew for a total of 8 persons with heating, ventilation and air-conditioning

Manager

Hermann Lohmann Bereederung GmbH & Co., KG

Hafenstrasse 16

49733 Haren (Ems)

Germany

Registered owner

H. Lohmann Schiffahrts GmbH & Co KG MS " MARAS "

Renamed

04/2022 Celtic Explorer

Antigua & Barbuda, St. John’s - Call sign: V2QY6

Owner & manager: Charles M Willie & Co Shipping, Cardiff - United Kingdom

Latest data adjustment

31 October 2024
