| Westerschelde 04 February 2017 |
 |
 |
|
| Westerschelde 04/02/17 | WS 04/02/17 | |
|
Name |
TIAN SHOU |
|
Type |
Multi-purpose and heavy lift carrier - Strengthened for heavy cargoes |
|
IMO-number |
9704752 |
|
Call sign |
9V9249 |
|
Flag |
Republic of Singapore |
|
Port of registry |
Singapore city |
|
Previous flags |
2016 - 2023 Hong Kong - China, Hong Kong - Call sign: VRPA4 2023 - 2024 Liberia, Monrovia - Call sign: 5LIF8 |
|
GT |
26.600 |
|
DWT |
38.134 t |
|
NT |
11.395 |
|
Number of 20ft containers |
On deck: 1.015 |
|
Length |
189,99 m overall 187,00 m between perpendiculars |
|
Breadth |
28,50 m moulded |
|
Draught |
Summer: 11,00 m |
|
Forecastle |
16,09 m |
|
Poop |
20,29 m |
|
Deckhouse |
14,29 m |
|
Freeboard |
4.832 mm |
|
Depth |
15,80 m moulded |
|
Speed |
Max: 15,6 knots |
|
Build |
2016 |
|
Date of completion |
26/01/2016 |
|
Builder |
Nantong COSCO KHI Ship Engineering Co., Ltd. China |
|
Hull material |
Steel |
|
Hull type |
Double side skin |
|
Bulkheads |
10 |
|
Continuous decks |
1x Upper deck |
|
Main engine |
1x DMD/Wärtsilä 6RT-FLEX50-B - 6 cylinder combustion engine 6.960 kW / 9.465 bhp at 99,0 rpm Build: 17/07/2015 Builder: Dalian Marine Diesel Co.,Ltd. |
|
Propellers |
1 |
|
Boilers |
1x Exhaust composite boiler Heating surface: 274,00 / 21,00 m² Builder: Alfa-Laval Aalborg Industries K.K. |
|
Generators |
3x FE547C-8 main diesel generatorsets each 750 kW / 450 Volt |
|
Number of holds |
4 |
|
Cargo hold capacity |
Grain: Hold 1: 8.322,40 m³ Hold 2: 13.201,60 m³ Hold 3: 13.201,60 m³ Hold 4: 10.421,50 m³ Total: 45.447,1 m³ |
|
Number of hatches |
2x 33,55 x 23,20 m 1x 29,81 x 23,20 m 1x 13,22 x 23,20 m / 11,06 x 18,20 m |
|
Tank capacities |
Ballast: 14.488 m³ |
|
Lifting equipment |
1x Crane - SWL 4,0 t |
|
Cargo gear |
1x deck crane - SWL 80 t 3x deck cranes - SWL 100 t each |
|
Manager |
COSCO Shipping Specialized Carriers (Southeast Asia) Pte. Ltd. 30 Cecil Street, #25-01 Prudential Tower Singapore 049712 Republic of Singapore |
|
Registered owner |
COSCO Shipping Specialized Carriers (Southeast Asia) Pte. Ltd. |
|
Latest data adjustment |
22 January 2025 |
