| Westerschelde 27 September 2012 |
 |
 |
 |
 |
 |
 |
|||||
| Brugge 23/07/14 | Brugge 23/07/14 | Brugge 23/07/14 | Brugge 23/07/14 | Antwerpen 23/07/19 | Antwerpen 23/07/19 |
|
Name |
ARINA |
|
Previous names |
1989 - 01/2006 Sofia |
|
Type |
General cargo ship - Equipped for carriage of containers - Strengthened for heavy cargo |
|
IMO-number |
8806163 |
|
Call sign |
LYRY |
|
Flag |
Lithuania |
|
Port of registry |
Klaipéda |
|
GT |
3.826 t |
|
DWT |
4.402 t |
|
NT |
2.043 t |
|
Number of 20ft containers |
In hold: 140 On deck: 204 Total: 344 |
|
Container capacity 14t |
230 |
|
Reefer points |
34 |
|
Length |
104,81 m overall 97,92 m registered |
|
Breadth |
16,25 m moulded |
|
Draught |
5,78 m fully laden |
|
Forecastle |
11,12 m |
|
Poop |
9,80 m |
|
Freeboard |
1.882 m |
|
Depth |
7,75 m |
|
Speed |
15,4 knots |
|
Built |
1989 |
|
Keel laid |
22/02/1989 |
|
Launch date |
04/04/1989 |
|
Date of completion |
05/1989 |
|
Builder |
J.J. Sietas KG Schiffswerft GmbH & Co. Neuenfelder Fährdeich 88 21129 Hamburg Federal Republic of Germany |
|
Yard number |
1039 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Partly double bottom (e.g. interrupted in way of machinery space) |
|
Watertight bulkheads |
5 |
|
Continuous decks |
2 |
|
Main engine |
1x Wärtsilä 8R32D - 4 stroke 8 cylinder 320 x 350 mm combustion engine 2.960 kW at 720 rpm Year of manufacture: 1988 Manufacturer: Oy Wärtsilä Ab 65101 Vaasa Finland |
|
Propellers |
1x Controllable pitch propeller - aft at 169 rpm |
|
Electric installation |
2x Plants each 400/220 V - 185 kVA 1x Plant 400 V - 675 kVA 1x Plant 400 V - 25 kVA |
|
Shaft generator |
1x 675 kVA / 540 kW |
|
Generators |
2x Main diesel generatorsets each 185 kVA |
|
Emergency generator |
1x Diesel generatorset 25 kVA |
|
Compressed air receivers |
2x Receivers each 250 litres - 30,0 bar 1x Receiver 500 litres - 11,0 bar |
|
Bow thruster |
1x Fixed pitch propeller PLEUGER - 300 kW, forward |
|
Number of holds |
1 |
|
Number of hatches |
1 Hatch 1: 65,07 x 12,82 m |
|
Cargo capacity |
Grain: 6.461 m³ Bales: 6.368 m³ |
|
Tank capacity |
Fuel oil: 288 m³ / 273 t gas oil: 66 t Ballast water: 1.916 m³ |
|
Anchor equipment |
3x Anchors weight each 2.850 kg Chain Length: 495,00 m Diameter: 42 mm |
|
Crew size |
10 |
|
Manager |
Afalita Shipping UAB Naujoji Uosto g. 11 92121 Klaipeda Lithuania |
|
Registered owner |
Markolio Shipping Co. Ltd. 13 Georgiou Karaiskakis Street 3032 Limassol Republic of Cyprus |
|
Latest data adjustment |
27 May 2020 |
