| Westerschelde 30 January 2015 |
 |
 |
 |
 |
|||
| Westerschelde 30/01/15 | Antwerpen 15/07/11 | Westerschelde 14/03/20 | Westerschelde 14/03/20 |
|
Name |
BERTHOLD K |
|
Previous name |
05/2008 - 09/2009 Union Ruby |
|
Type |
Multi-purpose dry cargo ship - Strengthened for heavy cargo |
|
IMO-number |
9374715 |
|
Call sign |
PBUN |
|
Flag |
The Netherlands |
|
Port of registry |
Delfzijl |
|
Previous flag |
05/2008 - 09/2009 Isle of Man - United Kingdom - Call sign: 2AEK2 |
|
GT |
2.967 t |
|
DWT |
Summer: 4.442,9 t |
|
NT |
1.601 t |
|
Number of 20ft containers |
38 |
|
Length |
89,92 m overall 84,94 m between perpendiculars 84,82 m registered |
|
Breadth |
14,63 m extreme 14,40 m moulded |
|
Draught |
6,22 m |
|
Forecastle |
7,22 m |
|
Poop |
11,10 m |
|
Depth |
7,85 m moulded |
|
Speed |
Max.: 13,0 knots Service: 11,0 knots |
|
Built |
2008 |
|
Keel laid |
23/05/2006 |
|
Launch date |
24/12/2007 |
|
Date of completion |
29/05/2008 |
|
Builder |
Chowgule & Company Pvt. Ltd. Shipbuilding Division Loutulim Near Borim Bridge Loutulim Road Loutulim , Goa 403 718 Republic of India |
|
Yard number |
C0182 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
2x Moveable to 9 positions, grain bulkheads |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 6M25 - 4 stroke single acting 6 cylinder 255 x 400 mm combustion engine 1.980 kW at 750 rpm Year of manufacture: 2006 Manufacturer: Caterpillar Motoren GmbH & Co. KG Falckensteiner Str. 2 24159 Kiel Federal Republic of Germany |
|
Propeller |
1x 'Berg' controllable pitch propeller - aft at 158 rpm |
|
Electric installations |
1x Plant 400 V - 350 kVA 1x Plant 400 V - 390 kVA 1x Plant 400 V - 175 kVA |
|
Shaft generator |
1x Stamford - 390 kVA/ 320 kW |
|
Generators |
2x Sisu 634 DSBIG main diesel generatorsets each 175 kVA / 150 kW |
|
Emergency generator |
1x Sisu 634 DSBIG diesel generatorset 175 kVA |
|
Compressed air receivers |
2x Receivers each 500 litres - 30,0 bar |
|
Bow thruster |
1x Transverse thruster 250 kW, forward |
|
Hold dimension |
56,55 x 10,20 x 7,99 m |
|
Cargo capacity |
5.753 m³ / 205.463 ft³ |
|
Type of hatch covers |
Pontoon operated by gantry crane |
|
Max. cargo load |
On tank top: 15 t/m² |
|
Cargo hold ventilation |
6x Air exchanges / hour |
|
Tank capacities |
Ballast: 1.919 m³ Fresh water: 50 m³ Gas oil: 282 m³ |
|
Anchor equipment |
3x Anchors weight each 2.100 kg Anchor chain: 440,00 m Diameter: 36 mm |
|
Manager |
Bereederungsgesellschaft Alstership GmbH & Co. KG An der Alster 85 20099 Hamburg Federal Republic of Germany |
|
Previous managers |
2008 - 2008 Cholerton Ltd. 05/2008 - 09/2009 Union Transport Group PLC., - Isle of Man |
|
Owner |
Rederij K&T Holland C.V. XII |
|
Previous owners |
05/2008 - 09/2009 Union Transport Group PLC., - Isle of Man 2009 - 2014 Rufinia Beheer B.V., 9936 BH Farmsum - The Netherlands 2014 - 2014 Highland Shipping B.V. |
|
Latest data adjustment |
21 April 2020 |
