| Westerschelde 01 May 2017 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 01/05/17 | Antwerpen 14/08/17 | Antwerpen 26/02/13 | Antwerpen 30/10/13 | Antwerpen 14/12/15 | Antwerpen 03/05/16 | |||||
|
Name |
CROWN JADE |
|
Type |
Refrigerated cargo ship |
|
IMO-number |
9128051 |
|
Call sign |
C6DV2 |
|
Flag |
Bahamas |
|
Port of registry |
Nassau |
|
Previous flag |
1997 - 2018 Republic of Panama, Panama City - Call sign: 3FVE7 |
|
GT |
10.519 t registered Suez: 11.433 t |
|
DWT |
10.342 t |
|
NT |
5.406 t registered Panama: 8.862 t Suez: 9.350 t |
|
Number of 20ft containers |
210 |
|
Number of 40ft containers |
86 |
|
Reefer capacity |
70 |
|
Length |
151,99 m overall |
|
Breadth |
23,00 m |
|
Draught |
8,66 m |
|
Moulded L x B x D |
139,40 x 23,00 x 13,00 m |
|
Registered L x B x D |
141,15 x 23,00 x 13,00 m |
|
Freeboard |
Summer: 4.363 mm |
|
Depth |
13,0 m moulded |
|
Speed |
Max.: 22,8 knots |
|
Built |
1997 |
|
Keel laid |
08/08/1996 |
|
Launch date |
29/10/1996 |
|
Date of completion |
06/02/1997 |
|
Builder |
Iwagi Zosen Co., Ltd. Kamijima Japan |
|
Yard number |
S-Z166 |
|
Hull material |
Steel |
|
Main engine |
1x Mitsubishi 6UEC60LSII - 2 stroke single acting 6 cylinder 600 x 2.300 mm combustion engine 11.915 kW / 16.200 bhp at 105,0 rpm Manufacturer: Mitsubishi Heavy Industries, Ltd. Kobe Shipyard & Machinery Works |
|
Propellers |
1c Fixed pitch propeller |
|
Propeller shaft |
1x Oil lubrication shaft with monitoring device |
|
Boilers |
1x Auxiliary vertical boiler - 7,8 bar Evaporation: 3,49 t/h Manufacturer: Mitsubishi Heavy Ind., Ltd. (Marukin Sato Shipbuilding & Iron Products Co., Ltd.) |
|
Generators |
5x Diesel generatorsets - 3.810 kVA |
|
Reefer capacity |
15.505 m³ |
|
Hold capacity |
Bale: 547.600 m³ |
|
Deck area |
6.226 m² |
|
Holds / Compartments |
4 / 16 |
|
Hatch covers |
4 13,00 x 7,80 m each |
|
Temp min/max |
-30 / 15°C |
|
Tank capacities |
Fuel oil: 1.806 m³ Fresh water: 381 m³ Water ballast: 923 m³ |
|
Cargo gear |
2x Cranes - SWL 35,0 t each 2x Cranes - SWL 8,0 t each |
|
Crew |
25 |
|
ISM & commercial manager |
Ost-West-Handel Und Schiffahrt GmbH Breitenweg 10-12 28195 Bremen Germany |
|
Previous managers |
Wallem Shipmanagement Limited Norbulk Shipping U.K. LTD. |
|
Operator |
Cool Carriers AB Barnhusgatan 16 SE-111 23 Stockholm Sweden |
|
Registered owner |
Lexfor Investment Inc. Care of Ost-West-Handel und Schiffahrt GmbH Breitenweg 10-12 28195 Bremen Germany |
|
Previous owner |
1997 - 2001 Pacific Star Maritime Inc 2001 NYK Reefers Limited, London - United Kingdom |
|
Latest data adjustment |
23 November 2022 |
