| Westerschelde 11 September 2012 |
 |
| Westerschelde 11/09/12 |
|
Name |
SABINA |
|
Previous names |
1986 Atula - Egon Blohm KG ms "ATULA", Oldenburg - Germany 1994 RMS Mercator - Egon Blohm KG ms "ATULA" - Tuvalu 1996 Atula - Egon Blohm KG ms "ATULA" - Tuvalu 2006 Sabina - Helmer Lundström Ab Oy, Nivelax - Finland |
|
Type |
General cargo ship - Strengthened for heavy cargo |
|
IMO-number |
8616635 |
|
Call sign |
OJMJ |
|
Flag |
Finland |
|
Port of registry |
Västanfjärd |
|
GT |
2.006 t |
|
DWT |
2.722 t |
|
NT |
1.096 t |
|
Number of 20ft containers |
96 |
|
Length |
81,88 m overall 78,42 m registered |
|
Breadth |
12,60 m registered |
|
Draught |
4,503 m |
|
Forecastle |
9,00 m |
|
Poop |
12,62 m |
|
Depth |
4,75 m moulded |
|
Speed |
11,0 knots |
|
Built |
1986 |
|
Keel laid |
16.04.1986 |
|
Launch date |
15.11.1986 |
|
Date of completion |
12.1986 |
|
Builder |
Heinrich Brand Schiffswerft GmbH & Co. KG |
|
Yard number |
227 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Partly double bottom |
|
Watertight bulkheads |
5 |
|
Continuous decks |
2 |
|
Main engine |
1x KHD type SBV 6 M 628 - 4 stroke 6 cylinder 240 x 280 mm diesel engine - 1.185 kW at 1.000 rpm Year of manufacture: 1986 Manufacturer: Klöckner-Humboldt-Deutz AG |
|
Propellers |
1x Solid propeller - aft at 216 rpm |
|
Electric installation |
2x Plants each 400/220 V - 187,5 kVA 1x Plant 400 V - 118 kVA 1x Plant 400 V - 42 kVA |
|
Shaft generator |
1x 118 kVA |
|
Generators |
2x Main diesel generatorsets each 187,5 kVA |
|
Harbour generator |
1x Diesel generatorset 42 kVA |
|
Compressed air receivers |
2x Receivers each 250 litres - 30,0 bar |
|
Bow thruster |
1x Transverse thruster HATLAPA - 162 kW, forward |
|
Number of holds |
1x Boxshaped hold 51,34 x 10,15 x 6,975 m 2x movable bulkheads |
|
Number of hatches |
1 51,34 x 10,15 m Max load on hatch covers 1,35 t/m² |
|
Tanktop strength |
12,5 t/m² |
|
Cargo capacity |
Grain: 3.697 m³ / 130.572 ft³ Bales: 3.692 m³ / 130.378 ft³ |
|
Ballast water |
1.387 m³ |
|
Anchor equipment |
3x Anchors weight each 1.440 kg Chain length: 412,50 m |
|
Manager |
Lundström rederei |
|
Registered owner |
Helmer Lundström Ab Oy |
