Rickmers Tianjin - IMO 9480136

Name

RICKMERS TIANJIN

Type

Multi-Purpose dry cargo ship - Equipped for carriage of containers - Strengthened for heavy cargo

IMO-number

9480136

Call sign

A8ZP8

Flag

Liberia

Port of registry

Monrovia

GT

12.772 t

DWT

17.409 t

NT

5.641 t

Number of 20ft containers

On deck: 504

Under deck: 390

Total: 894

Number of 40ft containers

60

Container capacity 14t

630

Reefer capacity

60

Length

143,83 m overall

134,87 m registered

Breadth

22,80 m registered

Draught

9,85 m

Forecastle

9,97 m

Poop

15,10 m

Depth

13,35 m moulded

Speed

16,3 knots

Built

2011

Keel laid

22.01.2010

Launch date

06.03.2011

Date of completion

05.09.2011

Builder

Xinshun Shipyard Group Co., Ltd.
ShanWai, Huanghua Town
Yueqing City ,325605 Zhejiang
People's Republic of China

Yard number

XS0804

Hull material

Shipbuilding steel (standard)

Hull type

Partly double bottom

Watertight bulkheads

6

Continuous decks

2

Main engine

1x Wärtsilä NSD 6RTA48T-B - 2 stroke 6 cylinder 180 x 2.000 mm diesel engine - 8.730 kW at 127,0 rpm

Year of manufacture: 2009

Manufacturer: 3. Maj Motori i Dizalice d.d.
Liburnijska 3
51000 Rijeka
Croatia

Propellers

1x Solid propeller (keyless) - aft at 127,0 rpm

Boilers

1x Steam boiler, oil fired - 9,0 bar

1x Steam boiler, exhaust gas heated - 9,0 bar
Year of manufacture: 2009

Manufacturer: Alfa Laval Qingdao Ltd.
86 Guangzhou Road North Jiaozhou
Qingdao ,266300 Shandong
People's Republic of China

Electric installations

3x Plants 450 V - 900 kVA each

1x Plant 450 V - 125 kVA

1x Plant 24 V - 70 Ah

1x Plant 24 V - 200 Ah

Shaft generator

1

Generators

3x Main diesel generatorsets each 900 kVA

Emergency generator

1x Diesel generatorset 125 kVA

Batteries

2x Batteries for UPS navigation each 200 Ah

2x Batteries for start emergency engine each 70 Ah

Compressed air receivers

2x Receivers each 2.500 litres - 33,0 bar

1x Receiver 150 litres - 33,0 bar

1x Receiver 1.000 litres - 12,0 bar

Bow thruster

1x Transverse thruster - 700 kW, forward

Number of holds

3

Type of hatchcovers

MacGregor - hydraulic folding type

Cargo capacity

Grain: 18.800 m³

Max. permitted loads

Tank top: 20 t/m²

Hatch cover: 2,0 t/m²

Tweendeck:

3,0 t/m² for No.1
3,5 t/m² for No.2
3,5 t/m² for No.3

Anchor equipment

3x Anchors weight each 6.000 kg

Chain length: 577,50 m

Cargo gear

MacGregor
2x Electric-hydraulic type 150,0 t each capacity combinable
1x Electric-hydraulic type 80,0 t capacity

Crew size

20

Manager

Lubeca Marine (Germany) GmbH & Co. KG
Grosse Burgstr. 55-57
23552 Lübeck
Federal Republic of Germany

Operator

Rickmers Holding GmbH & Cie. KG
Neumühlen 19
22763 Hamburg
Germany

Registered owner

MS "GOTLAND" Schifffahrt GmbH & Co. KG
Pferdemarkt 6-8
23552 Lübeck
Federal Republic of Germany

Last update

10.05.2013
